Siemens Argus 7SR22 User Manual

7SR220 Settings Guide
Unrestricted ©2018 Siemens Protection Devices Limited Page 101 of 107
Description Range Default
Self Reset LEDs
LEDs selected, as Self Reset will automatically reset when the
driving signal is removed. By default all LEDs are Hand Reset
and must be manually reset either locally via the front fascia or
remotely via communications.
Combination of ( 1, 2, 3, 4, 5, 6, 7,
8, 9, 10, 11, 12, 13, 14 )
1, 9, 10, 11, 12,
13, 14
PU Self Reset LEDs
LEDs selected, as Self Reset will automatically reset when the
driving signal is removed. By default all PU LEDs are Self
Reset.
Combination of ( 1, 2, 3, 4, 5, 6, 7,
8, 9, 10, 11, 12, 13, 14 )
1, 2, 3, 4, 5, 6, 7,
8, 9, 10, 11, 12,
13, 14
Green LEDs
Selects which LEDs will be green when driven
Combination of ( 1, 2, 3, 4, 5, 6, 7,
8, 9, 10, 11, 12, 13, 14 )
--------------
Red LEDs
Selects which LEDs will be red when driven
Combination of ( 1, 2, 3, 4, 5, 6, 7,
8, 9, 10, 11, 12, 13, 14 )
1, 2, 3, 4, 5, 6, 7,
8, 9, 10, 11, 12,
13, 14
PU Green LEDs
Selects which LEDs will be green when driven by a pickup
Combination of ( 1, 2, 3, 4, 5, 6, 7,
8, 9, 10, 11, 12, 13, 14 )
1, 2, 3, 4, 5, 6, 7,
8, 9, 10, 11, 12,
13, 14
PU Red LEDs
Selects which LEDs will be red when driven by a pickup
Combination of ( 1, 2, 3, 4, 5, 6, 7,
8, 9, 10, 11, 12, 13, 14 )
1, 2, 3, 4, 5, 6, 7,
8, 9, 10, 11, 12,
13, 14
3.13.4. Pickup Config
Description Range Default
Gn P/F Pickups
When any of the selected pickups operate General Pickup is
driven.
Combination of ( 51-1, 51-2, 51-3,
51-4, 50-1, 50-2, 50-3, 50-4 )
51-1, 51-2, 51-3,
51-4, 50-1, 50-2,
50-3, 50-4
Gn E/F Pickups
As Above
Combination of ( 51N-1, 51N-2,
51N-3, 51N-4, 50N-1, 50N-2, 50N-
3, 50N-4, 51G-1, 51G-2, 51G-3,
51G-4, 50G-1, 50G-2, 50G-3, 50G-
4 )
51N-1, 51N-2,
51N-3, 51N-4,
50N-1, 50N-2,
50N-3, 50N-4,
51G-1, 51G-2,
51G-3, 51G-4,
50G-1, 50G-2,
50G-3, 50G-4
Gn SEF/REF Pickups
As Above
Combination of ( 51SEF-1, 51SEF-
2, 51SEF-3, 51SEF-4, 50SEF-1,
50SEF-2, 50SEF-3, 50SEF-4, 64H
)
51SEF-1,
51SEF-2,
51SEF-3,
51SEF-4,
50SEF-1,
50SEF-2,
50SEF-3,
50SEF-4, 64H
Gn Voltage Pickups
As Above
Combination of ( 27/59-1, 27/59-2,
27/59-3, 27/59-4, Vx 27/59, 47-1,
47-2, 59NIT, 59NDT )
27/59-1, 27/59-2,
27/59-3, 27/59-4,
Vx 27/59, 47-1,
47-2, 59NIT,
59NDT
Gn Freq Pickups
As Above
Combination of ( 81-1, 81-2, 81-3,
81-4, 81-5, 81-6 )
81-1, 81-2, 81-3,
81-4, 81-5, 81-6
Gn Misc Pickups
As Above
Combination of ( 46IT, 46DT, 37-1,
37-2, 37G-1, 37G-2, 37SEF-1,
37SEF-2 )
46IT, 46DT, 37-
1, 37-2, 37G-1,
37G-2, 37SEF-1,
37SEF-2
3.14. Maintenance
