Siemens Argus 7SR22 User Manual

7SR21 & 7SR22 Performance Specification
Unrestricted © 2013 Siemens Protection Devices Limited Page 55 of 68
2.25 50 AFD ARC Flash Detector
(Refer to 7XG31 Technical Manual for performance characteristics)
2.25.1 Reference
Parameter Value
50 AFD Setting 1, 2,...10 xIn
2.25.2 Operate and Reset Level
Attribute Value
I
op
Operate level
100 % Is, ± 10 %
Transient overreach (X/R £ 100) £ -30 %
Reset level
³ 95 % I
op
Repeatability
± 5 %
2.25.3 Operate and Reset Time
Attribute Value
t
basic
50AFD Overcurrent operate time 10 ms – 16 ms
t
op
AFD Zone operate time (Flash & 50AFD) 15 ms – 25 ms
Repeatability
± 10 ms
Disengaging time < 50 ms

Siemens Argus 7SR22 Specifications

General

Type	Feeder Protection Relay
Frequency	50/60 Hz
Binary Outputs	Up to 8
Current Inputs	1 A or 5 A
Communication	Ethernet, RS485
Protocols	Modbus, DNP3
Protection Functions	Overcurrent, Earth Fault, Thermal Overload
Operating Temperature	-25 to +70 °C
Humidity	5 to 95% non-condensing
