Siemens AVS75.390 - Dimensions and Drilling Plan; Checking the RF Components

33/221
Siemens Switzerland Ltd User manual RVS61.843 CE1U2355en_02
HVAC Products 3 Mounting and installation 23. November 2007
Dimensions and
drilling plan
90
100
32
2359Z16
12
2359Z27
4,2
56 60
56
60
3.8.5 Checking the RF components
To check whether the connections to the required system components are operational,
consult menus 130 through 135 on menu “Wireless“ (operating level “Commissioning“).
