44/221
Siemens Switzerland Ltd User manual RVS61.843 CE1U2355en_02
HVAC Products 5 Handling 23. November 2007
5.1.4 Overview of the settings
The table below shows all available settings up to the heating engineer level. Certain
operating lines may be hidden, depending on the unit version in use.
E = enduser
I = commissioning
F = heating engineer
BZ = operating line
1)
Only QAA75../78..
Operating
line
operating
Function
Default value
Minimum
Max
Unit
Time of day and date
1 E Hours/minutes - 00:00 23:59 hh:mm
2 E Day/month - 01.01 31.12 dd.MM
3 E Year - 2004 2099 yyyy
5 F Start of summertime 25.03 01.01 31.12 dd.MM
6 F End of summertime 25.10 01.01 31.12 dd.MM
Operator section
20 E Language
German ¦ …
German -
22 F Info
Temporarily ¦ Permanently
Temporarily -
26 F Operation lock
Off ¦ On
Off. -
27 F Programming lock
Off ¦ On
Off. -
28 I Direct adjustment
Automatic storage ¦ Storage with confirmation
Storage with confirmation
40
1)
I
Used as
Room unit 1 ¦ Room unit 2 ¦ Room unit P ¦ Operator unit 1
¦ Operator unit 2 ¦ Operator unit P ¦ Service unit
Room unit 1 -
42
1)
I Assignment device 1
Heating circuit 1 ¦ Heating circuits 1 and 2 ¦ Heating
circuits 1 and P ¦ All heating circuits
Heating circuit 1 -
44 I Operation HC2
Commonly with HC1 ¦ Independently
Commonly with HC1 -
46 I Operation HCP
Commonly with HC1 ¦ Independently
Commonly with HC1 -
48
1)
I Action occupancy button
None ¦ Heating circuit 1 ¦ Heating circuit 2 ¦ Commonly
Heating circuit 1 -
54
1)
F Readjustment room sensor 0.0 -3 3 °C
70 F Software version - 0 99.9 -
Wireless
120 I Binding
No ¦ Yes
No -
121 I Test mode
Off ¦ On
Off. -
130 I Room unit 1
Missing ¦ Ready ¦ No recept’n ¦ Change batt
- -
131 I Room unit 2
Missing ¦ Ready ¦ No recept’n ¦ Change batt
- -
132 I
Room unit P
Missing ¦ Ready ¦ No recept’n ¦ Change batt
- -
133 I
Outside sensor
Missing ¦ Ready ¦ No recept’n ¦ Change batt
- -
