Siemens AVS75.390 - Page 45

45/221
Siemens Switzerland Ltd User manual RVS61.843 CE1U2355en_02
HVAC Products 5 Handling 23. November 2007
Operating line operating
level
Function Default value Minimum Max Unit
134 I
Repeater
Missing ¦ Ready ¦ No recept’n ¦ Change batt
- -
135 I Operator unit 1
Missing ¦ Ready ¦ No recept’n ¦ Change batt
- -
136 I Operator unit 2
Missing ¦ Ready ¦ No recept’n ¦ Change batt
- -
137 I
Operator unit P
Missing ¦ Ready ¦ No recept’n ¦ Change batt
- -
138 I Service unit
Missing ¦ Ready ¦ No recept’n ¦ Change batt
- -
140 I Delete all devices
No ¦ Yes
No -
Time prog heating circuit 1
500 E Preselection
Mo - Su ¦ Mo - Fr ¦ Sa - Su¦ Mo ¦ Tu ¦ We ¦ Th ¦ Fr ¦ Sa ¦Su
Mo - Su -
501 E
1st phase on
06:00 00:00 24:00 hh:mm
502 E 1st phase off 22:00 00:00 24:00 hh:mm
503 E
2nd phase on
24:00 00:00 24:00 hh:mm
504 E
2nd phase off
24:00 00:00 24:00 hh:mm
505 E 3rd phase on 24:00 00:00 24:00 hh:mm
506 E
3rd phase off
24:00 00:00 24:00 hh:mm
516 E Default values
No ¦ Yes
No 1 -
Time prog heating circuit 2
520 E Preselection
Mo - Su ¦ Mo - Fr ¦ Sa - Su ¦ Mo¦ Tu ¦ We ¦ Th ¦ Fr ¦ Sa ¦Su
Mo - Su -
521 E
1st phase on
06:00 00:00 24:00 hh:mm
522 E 1st phase off 22:00 00:00 24:00 hh:mm
523 E
2nd phase on
24:00 00:00 24:00 hh:mm
524 E
2nd phase off
24:00 00:00 24:00 hh:mm
525 E 3rd phase on 24:00 00:00 24:00 hh:mm
526 E
3rd phase off
24:00 00:00 24:00 hh:mm
536 E Default values
No ¦ Yes
No 1 -
Time program 3 / HCP
540 E Preselection
Mo - Su ¦ Mo - Fr ¦ Sa - Su ¦ Mo ¦ Tu ¦ We¦ Th ¦ Fr ¦ Sa ¦Su
Mo - Su -
541 E
1st phase on
06:00 00:00 24:00 hh:mm
542 E 1st phase off 22:00 00:00 24:00 hh:mm
543 E
2nd phase on
24:00 00:00 24:00 hh:mm
544 E
2nd phase off
24:00 00:00 24:00 hh:mm
545 E 3rd phase on 24:00 00:00 24:00 hh:mm
546 E
3rd phase off
24:00 00:00 24:00 hh:mm
556 E Default values
No ¦ Yes
No 1 -
Time program 4 / DHW
560 E Preselection
Mo - Su ¦ Mo - Fr ¦ Sa - Su ¦ Mo ¦ Tu¦ We ¦ Th ¦ Fr ¦ Sa ¦Su
Mo - Su -
561 E
1st phase on
00:00 00:00 24:00 hh:mm
562 E 1st phase off 05:00 00:00 24:00 hh:mm
563 E
2nd phase on
24:00 00:00 24:00 hh:mm
564 E
2nd phase off
24:00 00:00 24:00 hh:mm
565 E 3rd phase on 24:00 00:00 24:00 hh:mm
