Structure and function
28
Building Technologies A6V10209291_f_en_--
Fire Safety & Security Products 05.02.2010
For details, see table below.
The CO sensor can only be monitored for failure. For a functional test, the CO
sensor must be tested with test gas.
When a fatal error (one which impairs the detector's function) occurs, a fault
message is signaled. To correct the cause of the fault, additional information is
available in the detector. This can be displayed by the FDUD292 detector
exchanger and tester or FDUD293 intelligent detector tester for example.
For details, see Documents 007227 and 009718.
Information displayed on the
detector exchanger and
tester
Meaning Actions
'no deviation' Normal, no fault is present
The detector is fully functional
None
'maybe excha.'
1
Observe information
The detector is fully functional
Slightly soiled
Check cause during periodic maintenance
'advice excha.'
1
Replacement recommended
Detector is still functional, in spite of minor
problems:
 Average soiling
 Untypical sensor values caused by
environmental influence
 Remedy the cause during the next
maintenance
 Replace detector if necessary
'needed excha.'
1
Replacement necessary
Detection possibly restricted; alarming is
still possible:
 Heavily soiled, failure of one optical
sensor
 Failure of one or both thermal sensors
 Failure of CO sensor for CO-supported
parameter set selected. The detector is
however still functioning as FDOOT.
 Inform maintenance service
 Replace detector
Supply error  Check detector line voltage
 Replace detector
Software error (Watchdog error) Replace detector
Memory error Replace detector
Any fault message
2
Communication error involving detector and
control panel
Remedy cause
1
The information displayed on the detector exchanger and tester is always in
English; no translation into the corresponding language.
2
This status can be displayed together with another status, e.g. 'needed excha.'
(replacement necessary).
