Siemens FDOOTC241 - Base Attachment Humid FDB293

Mounting / Installation
61
Building Technologies A6V10209291_f_en_--
Fire Safety & Security Products 05.02.2010
5.5 Base attachment humid FDB293
 For the installation of detectors in wet rooms, the base attachment humid
FDB293 is used.
 To seal the cables, especially tight cable glands are used.
max. 4mm Ø
max. 4mm Ø
FDB293
FDB221
FDB221-AA
FDB222
1
2
Installation of detector base on base attachment humid FDB293
1 Base attachment humid 2 Detector base
