5.4 Base attachment FDB291
 When the cable diameter is more than 6 mm, the base attachment FDB291
must be used.
 The required cable entries must be broken out on the base attachment.
119
25
max. 90
min. 46
max. Ø 4mm
FDB291
max. Ø 21m
m
FDB221
FDB221-AA
FDB222
1
2
3
Installation of detector base on base attachment FDB291
1 Identification 3 Detector base
2 Base attachment
