4.2.2.3 Specification
The table below shows the characteristics and fields of application of the parameter
sets for CO of neural fire detector FDOOTC241.
Response thresholds of warning levels 1 to 3,
technical CO alarm
[ppm CO]
No. Name
1 2 3
Response time, warning level
3 technical CO alarm
[min]
Alarming
according to
standard
0 Robust EU1 30 60 –
1
– –
1 Balanced EU2
@ 33 ±3 ppm CO
@ 55 ±5 ppm CO
@ 110 ±10 ppm CO
@ 330 ±30 ppm CO
30 50 – –
≥120
60 … 90
10 … 40
≤3
EN 50291
4 Static 40 30 35 40 – –
5 Static 50 30 40 50 – –
6 Static 60 30 45 60 – –
7 Balanced US1
@ 70 ±5 ppm CO
@ 150 ±5 ppm CO
@ 400 ±10 ppm CO
30 50 – –
60 … 240
10 … 50
4 … 15
UL 2034
1
Warning level 3 is not output in the default parameter set (not configured).
Example for parameter set 1 'Balanced EU2' @ 55 ±5 ppm CO:
At 50 ppm CO, alarming must take place after between 60 and 90 minutes.
At an ambient temperature of ≥ 80 °C, the CO sensor may not function reliably.
Irreversible signaling of a critical fault therefore follows.
The FDOOTC241 may only be used in continuous operation within the specified
temperatures!
See also
Technical data [ 78]
