Siemens FDOOTC241 - Parameter Sets: Sensor Mode 1 Heat Detector; Parameter Sets: Sensor Mode 2 Smoke Detector

Planning
45
Building Technologies A6V10209291_f_en_--
Fire Safety & Security Products 05.02.2010
4.1.3 Parameter sets: Sensor mode 1 'heat detector'
This sensor mode is especially suited for applications where the detector should
only react thermally.
No. Name
0 A1R
1 A1R
2 BR
3 A1S
4 BS
All parameter sets meet the criteria of standard EN 54-5.
4.1.4 Parameter sets: Sensor mode 2 'smoke detector'
Select sensor mode 2 when fast temperature changes may occur which are not
caused by fire (e.g. radiant heaters, hot engines). In this sensor mode the detector
only reacts optically; this is comparable with a wide-spectrum smoke detector.
Thanks to a second optical sensor, however, it display an optimized response
behavior in relation to the different types of fire.
Robust (2):
This parameter set reacts to aerosols in a similar way as the neural fire detector
FDOOTC241 in sensor mode 0 with the 'Robust' parameter set, without taking into
account the temperature.
Universal (1):
With 'Universal' the sensitivity and response time to aerosols are between 'Robust'
and 'Sensitive'.
Sensitive (3):
With regard to aerosols, this parameter set reacts in a way that is comparable to
'Fast Response' in sensor mode 0 without temperature influence.
No. Name Response time [s] Sensitivity open fire / smoldering fire [%/m]
0 Universal 50 2.3 / 8
2 Robust 80 2.3 / 8
1 Universal 50 2.3 / 8
3 Sensitive 30 1.6 / 5.6
All parameter sets meet the criteria of standard EN 54-7.
