4.1.2.3 Specification
The following table shows the characteristics and fields of application of the
parameter sets of neural fire detector FDOOTC241.
Optical Thermal
Typ. response
time
from - typ. - to
Sensitivity,
open fire
Sensitivity,
smoldering fire
Static
activation
temperature
Differential activation
temperature
(temperature
increase > 10 K/min)
Differential
activation
possible from:
No. Name
[s] [%/m] [%/m] [°C] ∆T [K] [°C]
8 High Suppression
(as of ES ≥30)
2
60 - 80 - 360 2.3 8 80 25 30
5 Suppression
3
90 - 160 - 760 3.2 11.4 80 29 30
12 Suppression CO
1
75 - 150 - 760 3.2
5
8.6 … 11.4
4
80 29 30
7 High Compensation 80 3.2 11.4 80 29 30
0 High Compensation 80 3.2 11.4 80 29 30
2 Robust 80 3.2 11.4 80 29 30
4 Balanced 40 - 64 - 300 2.3 8 80 25 30
10 Balanced CO
1
25 - 50 - 300 2.3
5
5 … 8
4
80 25 30
6 Fast Response 20 - 30 1.6 5.6 80 22 3
9 High Sensitive Fast 20 - 30 0.8 2.8 60 16 3
14
15
Application-specific parameter sets
1
The CO signal helps to speed up alarm activation in the event of smoldering fires but
cannot trigger fire alarms on its own.
2
Note chapter '4.1.3.1 Description', 'High Suppression (8)' paragraph.
3
Only implemented for reasons of compatibility. If the 'Suppression (5)' parameter set is
needed, 'Suppression CO (12)' should be used for new applications.
4
Depends on CO proportion.
5
In the case of open fires, the proportion of CO in the fire gas make-up is low. With
higher proportions of CO, the sensitivity could theoretically increase to up to 0.5 %/m
(i.e. e.g. instead of 2.3 %/m to 1.8 … 2.3 %/m) with open fires.
The static activation temperature of 80 °C is higher than the permanently
approved operating temperature range of the electro-chemical cells used for CO
detection.
The detector may only be used in continuous operation within the specified
temperatures!
All parameter sets except for 8 comply with standards EN 54-7 and CEA 4021.
