5.7 Designation plate FDBZ291
To provide the detector with a location address, the address is inscribed on the
designation plate FDBZ291 and placed on the detector base or base attachment.
FDB291
FDBZ291
FDB221
FDB221-AA
FDB222
FDBZ291
1
2
1
3
4
Installation of designation plate FDBZ291
1 Designation plate 3 Identification
2 Base attachment 4 Detector base
5.8 Designation plate DBZ1193A
To identify a detector on a base attachment humid, the detector designation plate
DBZ1193A is labelled and placed on the detector base humid FDB293.
FDB29
3
DBZ1193A
1
2
Installation of designation plate DBZ1193A
1 Designation plate DBZ1193A 2 Base attachment humid FDB293
