p0756 [0] - AI 0 (0-4) 0: Unipolar voltage input (0 V...10 V)
1: Unipolar voltage input monitored (2 V... 10 V)
2: Unipolar current input (0 mA…20 mA)
3: Unipolar current input monitored (4 mA…20 mA)
4: Bipolar voltage input (-10 V...10 V)
6: LG-Ni1000 temperature sensor (-50 °C…150 °C)
7: PT1000 temperature sensor (-50…250 °C)
8: No sensor connected
p0756 [1] - AI 1 (0-4)
p0756 [2] - AI 2 (2-3, 6-8)
p0756 [3] - AI 3 (6-8)
p0771[0] - AO 0 Important status signals:
0: Analog output locked
21: Speed actual value
24: Output frequency, smoothed
25: Output voltage smoothed
26: DC link voltage, smoothed
27: Actual current value (smoothed absolute value)
p0771[1] - AO 1
p0776[0, 1] - Analog outputs, type
0: Current output (0 mA...20 mA)
1: Voltage output (0 V...10 V)
2: Current output (4 mA...20 mA)
p0840 r0722.0 ON/OFF1 signal source
p0852 1 Enable operation
Is used to let the motor coast to a standstill if the ON command is
enabled. Example: P0852 = r0722.0.
p1000 2 Speed setpoint selection
2 = Analog setpoint
3 = Fixed speed
6 = Fieldbus
For further values, see the List Manual
p1082 1500 rpm Maximum motor speed in rpm
50Hz = 60Hz = 70Hz = 80Hz =
2-pole motor (rated
speed approx. 2750
– 3000 rpm)
3000 rpm 3600 rpm 4200 rpm 4800 rpm
4-pole motor (rated
speed approx. 1250
– 1500 rpm)
1500 rpm 1800 rpm 2100 rpm 2400 rpm
The reference speed (p2000) must be set to the same value.
p1113 r722.1 Invert direction of rotation
p1200 0 Flying restart selection:
0: Flying restart inactive
1: Flying restart always active (start in setpoint direction)
4: Flying restart always active (start only in setpoint direction)
