Function
Status
Symbol
Comments
Command
source
Manual No symbol is displayed if AUTO mode is activated.
Variable speed
drive
state
Ready Static symbol, does not rotate.
JOG function Active Is displayed if the JOG function is activated.
Fault or alarm
display
Fault or
alarm
● Flashing symbol:
– A command is active.
– The variable speed drive stops. Clear the fault.
● Non-flashing symbol:
– There is an alarm (e.g., overtemperature).
– The variable speed drive keeps running.
Table 6: BOP-2 screen symbols
4.3 License terms
The variable speed drive contains open source software (OSS). The license terms
for the open source code are stored in the variable speed drive.
Transferring the license terms
To transfer the OSS license terms from the variable speed drive to a PC, proceed
as follows:
1. Switch off the variable speed drive power supply.
2. Insert an empty memory card into the card slot of the variable speed drive.
3. Switch on the variable speed drive power supply.
4. When you have switched on the power supply, wait 30 seconds. During this
time, the device writes the "Read_OSS.ZIP" file onto the memory card.
5. Switch off the variable speed drive power supply.
6. Remove the card from the device.
7. Use a card reader to import the file to a PC.
For information about firmware upgrade and downgrade options, please go to
http://support.automation.siemens.com/WW/news/en/67364620.
