7.12 Fans in 87 Hz operation
Example for the following motor:
Figure 26: Example motor for 87 Hz operation
Carry out basic commissioning with 230V data
● IOP-2/BOP-2: Select "87 Hz characteristic".
● Starter: Select connection type "Delta" and "87 Hz calculation".
Parameter
Value
Description
p0304 230 V Rated motor voltage
p0305 0.73 A Rated motor current
p0307 0.12 kW Rated motor output
p0308 0.75 Motor cosPhi:
p0310 50 Hz Motor frequency
p0311 1350 rpm Rated motor speed
