Connecting printer, modem or P
C
A31003-K16-X001-3-7620, 07/99
Hicom 100 E Version 2.1, Service manual
5-17
Installation
Figure 5-10 Pin assignment of the printer adapter
RxD2
RTS7
GND5
RxD3
DSR6
DCD8
DTR20
GND7
CASDT printer
S30122-K5597-X
Suitable for:
SIEMENS P500
EPSON LX series
9-pin
SubD plug
25-pin
SubD plug
