nalogue trunk
Programming guide
A31003-K16-X001-3-7620
,
07/99
10-6
Hicom 100 E Version 2.1, Service manual
10.2.4 Changing line length
The default entry "Short line" may have to be replaced by "Long line" in order to match the level
of the relevant line(s) when the attendant console and the system are very far apart. Description
of error: invalid selection or call inaudible. This entry can be assigned per analogue trunk line.
Example
: analogue trunk line 1 is to be defined as a "long line".
Input sequence Meaning Display
A 204
Length of line 1
(select line 1- 32 with "+" and "–" or
directly with "#")
Line 1: short
B*
Change input Line 1
C
1 1 for "long line" Line 1: long
D<OK>
Confirm input Line 1: long
E<F8>
Return to Start menu System administration
The "short line" status can be reset by entering "0" under point C.
