Hicom 118 system overvie
w
A31003-K16-X001-3-7620, 07/99
Hicom 100 E Version 2.1, Service manual
2-7
System data
2.7 Hicom 118 system overview
Figure 2-4 Hicom 118 structural concept
Slots 1 to 4 for system extensions
:
Freely assignable with line and/or subscriber modules (see Table 3-12)
4
3
2
1
Cover/MDF
Basic system
Function expansions
Hicom 118
1
2
3
4
PSU2/UPS2
Plug in and
secure (screw)
Plug in
System expansion
System expansion
