Basics of operation
11
System and application bar
Recurring information and display keys appear in the system bar and the
application bar of the display (Æ Page 9) of your
optiPoint application module in different situations.
On being clicked, the display keys execute standard functions.
In the left area of the system bar:
The currently selected application/function is displayed here.
In the right area of the system bar:
Opens the display keyboard for entering characters Æ Page 14.
Takes the user from the current application to the start page without
quitting the application Æ Page 9.
Invokes the Help function Æ Page 60.
In the left area of the application bar:
Display keys with different text content are displayed here. They execute
application-dependent functions.
If several alternatives are offered, the selected display key is highlighted in
yellow. Examples:
Active display key:
The function is executed on clicking (or pressing the
t key).
Neutral display key.
In the right area of the application bar:
Quits the current application.
Modifications that have not been saved are lost.
Opens / closes the context menu with useful functions suitable for the
current application situation (the k key offers the same functionality).
Select
Display
To Next Page
