Step by Step
Administration
46
Configuring the LDAP Server
Perform the following steps to enter the LDAP server IP
address and port number.
1. Start the web-based management tool, see
 Page 51.
2. Select "Administration" > [password] >
"Applications" > "LDAP", see
 Page 56.
3. Enter the IP address of the LDAP server, see
 Page 80.
4. Click "Submit".
5. Select "System" > "Port Settings", see  Page 66.
6. Enter the port number for communication with the
LDAP server, see
 Page 80.
7. Click "Submit".
Installing the LDAP Template
Perform the following steps to transfer the template to
your optiPoint display
module:
1. Make sure that an FTP server is available, see
 Page 102 and that the relevant template file is
stored on the server.
2. Start the web-based management tool, see
 Page 51.
3. Select "Administration" > [password] > "File
Transfer", see
 Page 60.
4. Enter the following parameters:
– FTP server address, see  Page 76
– FTP account name, see  Page 75
– FTP user name, see  Page 76
– LDAP template file name, see  Page 82
5. Select "Download LDAP template" from the field
"Action on submit", see
 Page 68.
6. Click "Submit".
A standard template is already installed. You can
also install a template that corresponds to your
personal criteria. See  Page 80 for an example
of this template.
