No. Parameter
mask
Parameter
internal
Data type Meaning
4 Z1 <DP> REAL Drilling depth (abs), see <_AMODE>
5 Z1 <DPR> REAL Drilling depth (inc), see <_AMODE>
6 DT <DTB> REAL Dwell time at final drilling depth, see <_AMODE>
7 <_GMODE> INT Geometrical mode (evaluation of programmed geometrical data)
UNITS: Reserved
TENS: Drilling depth with respect to tip/shank
0 = Compatibility, tip
1 = Shank
8 <_DMODE> INT Display mode
UNITS: Machining plane G17/G18/G19
0 = Compatibility, the plane effective
before the cycle call remains ac‐
tive
1 = G17 (only active in the cycle)
2 = G18 (only active in the cycle)
3 = G19 (only active in the cycle)
TENS: Reserved
HUNDREDS: Reserved
THOUSANDS: Reserved
TEN THOUSANDS: Technology scaling in cycle screen forms
(Page 1153)
0 = Input: Complete
1 = Input: Basic
Work preparation
3.25 Programming cycles externally
NC programming
1066 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
