4.4 Predefined procedures
The call of a predefined procedure triggers the execution of a predefined NC function. A
predefined procedure does not supply a return value in contrast to a predefined function.
Coordinate system
Identifier Parameter Explanation
1. 2. 3. - 15. 4. - 16.
PRESETON AXIS *
)
:
Axis identifier
of
machine axis
REAL:
Preset offset
G700/G710
context
As 1 ... As 2 ... Set actual value for the programmed
axes with loss of the referencing sta‐
tus
PRESETONS AXIS *
)
:
Axis identifier
of
machine axis
REAL:
Preset offset
G700/G710
context
As 1 ... As 2 ... Set actual value for the programmed
axes without loss of the referencing
status
DRFOF Deletes the DRF offset for all axes
assigned to the channel.
)
As a general rule, geometry or special axis identifiers can also be used instead of the machine axis identifier, as long as the
reference is unambiguous.
Axis groupings
Identifier Parameter Explanation
GEOAX 1. 2. 3. / 5. 4. / 6. Selection of a parallel coordinate sys‐
tem
INT:
Geometry ax‐
is number
1 ... 3
AXIS:
Channel axis
identifier
As 1 As 2
FGROUP 1. – 8. Variable F value reference: Definition
of the axes to which the path feed re‐
fers
Maximum number of axes: 8
The default setting for the F value ref‐
erence is activated with FGROUP ( )
without parameters
AXIS:
Channel axis identifier
SPLINEPATH 1. 2. – 9. Definition of the spline grouping
Maximum number of axes: 8
INT:
Spline group‐
ing (must be 1)
AXIS:
Geometry of additional identifier
POLYPATH 1. 2. Activation of the polynomial interpo‐
lation for selective axis groups
STRING STRING
Tables
4.4 Predefined procedures
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1267
