No. Parameter
mask
Parameter
internal
Data type Meaning
4 Z1/∅ <DP> REAL Drilling depth (abs) / centering diameter (abs), see <_GMODE>
5 Z1 <DPR> REAL Drilling depth (inc)
6 DT <DTB> REAL Dwell time at final drilling depth, see <_AMODE>
7 <_GMODE> INT Geometrical mode (evaluation of programmed geometrical data)
UNITS: Reserved
TENS: Centering with respect to depth/diameter
0 = Compatibility, depth
1 = Diameter
8 <_DMODE> INT Display mode
UNITS: Machining plane G17/G18/G19
0 = Compatibility, the plane effective
before the cycle call remains ac‐
tive
1 = G17 (only active in the cycle)
2 = G18 (only active in the cycle)
3 = G19 (only active in the cycle)
9 <_AMODE> INT Alternative mode
UNITS: Drilling depth Z1 (abs/inc)
0 = Compatibility, from DP/DPR pro‐
gramming
1 = Incremental
2 = Absolute
TENS: Dwell time at final drilling depth DT in
seconds/revolutions
0 = Compatibility, from DTB sign (> 0
seconds or < 0 revolutions)
1 = In seconds
2 = In revolutions
3.25.1.22 CYCLE82 - drilling, counterboring
Syntax
CYCLE82(<RTP>, <RFP>, <SDIS>, <DP>, <DPR>, <DTB>, <_GMODE>,
<_DMODE>, <_AMODE>, <_VARI>, <S_ZA>, <S_FA>, <S_ZD>, <S_FD>)
Parameter
No. Parameter
mask
Parameter
internal
Data type Meaning
1 RP <RTP> REAL Retraction plane (abs)
2 Z0 <RFP> REAL Reference point (abs)
3 SC <SDIS> REAL Safety clearance (to be added to reference point, enter without sign)
Work preparation
3.25 Programming cycles externally
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1065
