No. Parameter
mask
Parameter
internal
Data type Meaning
0 = Compatibility, as a factor (0.001
to 1.0, FRF = 0 means 100%)
1 = Percentage (0.001 to 999.999%)
3.25.1.24 CYCLE84 - tapping without compensating chuck
Syntax
CYCLE84(<RTP>, <RFP>, <SDIS>, <DP>, <DPR>, <DTB>, <SDAC>, <MPIT>,
<PIT>, <POSS>, <SST>, <SST1>, <_AXN>, <_PITA>, <_TECHNO>, <_VARI>,
<_DAM>, <_VRT>, <_PITM>, <_PTAB>, <_PTABA>, <_GMODE>, <_DMODE>,
<_AMODE>)
Parameters
No. Parameter
mask
Parameter
internal
Data type Meaning
1 RP <RTP> REAL Retraction plane (abs)
2 Z0 <RFP> REAL Reference point (abs)
3 SC <SDIS> REAL Safety clearance (to be added to reference point, enter without sign)
4 Z1 <DP> REAL Drilling depth = final drilling depth (abs), see <_AMODE>
5 Z1 <DPR> REAL Drilling depth = final drilling depth (inc), see <_AMODE>
6 DT <DTB> REAL Dwell time at drilling depth in seconds
7 SDE <SDAC> INT Direction of rotation after end of cycle
8 <MPIT> REAL Thread size for "ISO metric" only (pitch is calculated internally during run
time)
9 P <PIT> REAL Pitch as a value, for unit see <_PITA>
10 αS
1)
<POSS> REAL Spindle position for oriented spindle stop
11 S <SST> REAL Spindle speed for tapping
12 SR <SST1> REAL Spindle speed for retraction
13 <_AXN> INT Drilling axis 0 = 3rd geometry axis
1 = 1st geometry axis
2 = 2nd geometry axis
≥ 3 = 3rd geometry axis
14 <_PITA> INT Pitch unit (evaluation of <PIT> and <MPIT>)
0 = Pitch in mm - evalua‐
tion<MPIT>/
<PIT>
1 = Pitch in mm - evaluation<PIT>
2 = Pitch in TPI - evaluation of
<PIT>
(threads per inch)
3 = Pitch in inches - evaluation<PIT>
4 = MODULUS - evaluation<PIT>
Work preparation
3.25 Programming cycles externally
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1071
