Parameters
No. Parameter
mask
Parameter
internal
Data type Meaning
1 RP <_RTP> REAL Retraction plane (abs)
2 Z0 <_RFP> REAL Reference point of tool axis (abs)
3 SC <_SDIS> REAL Safety clearance (to be added to reference point, enter without sign)
4 Z1 <_DP> REAL Slot depth (abs/inc), see <_AMODE>
5 L <_LENG> REAL Length of slot (inc)
6 W <_WID> REAL Width of slot (inc)
7 X0 <_PA> REAL Reference point/starting position 1st axis (abs)
8 Y0 <_PO> REAL Reference point/starting position 2nd axis (abs)
9 α0 <_STA> REAL Angle of rotation with respect to 1st axis
10 DZ <_MID> REAL Maximum infeed depth (inc), for vortex milling only
11 DXY <_MIDA> REAL Maximum plane infeed, see <_AMODE>
12 UXY <_FAL> REAL Finishing allowance, plane
13 UZ <_FALD> REAL Finishing allowance, depth
14 F <_FFP1> REAL Feedrate
15 <_CDIR> INT Milling direction
UNITS:
0 = Down-cut
1 = Up-cut
4 = Alternating
16 <_VARI> INT Machining
UNITS:
1 = Roughing
2 = Finishing
3 = Base finishing
4 = Edge finishing
5 = Rough-finishing
6 = Chamfering
TENS: Reserved
HUNDREDS: Reserved
THOUSANDS:
1 = Vortex milling
2 = Plunge cutting
Work preparation
3.25 Programming cycles externally
NC programming
1114 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
