No
.
Screen
form pa‐
rameter
Cycle pa‐
rameter
Meaning
2 Selection S_KNUM Correction of work offset (WO) or basic WO or basic reference
2)
Val‐
ues:
UNITS:
TENS:
0 = No correction
1 to max. 99 numbers of the work offset or
1 to max. 16 numbers of the basic offset
HUNDREDS: Reserved
THOUSANDS: Correction of WO or basic or basic reference
0 = Correction of the adjustable WO
1 = Correction of the channel-specific basic WO
2 = Correction of the basic reference
9 = Correction of the active WO or for G500 in last active channel-specific basic WO
TEN THOUSANDS: Coarse or fine correction in the WO, basic WO or basic refer‐
ence
0 = Fine correction
5)
1 = Coarse correction
3 Icon+
number
S_PRNUM Number of the field of the probe parameters (not probe number)
(value range 1 to 40)
4 L1/X1 S_SETV0 Distance L1 between the pole and measuring point P1 in the direction of the 1st axis of the
plane (for G17 X)
3)
(if the actual distance L1=0, then L1 = M_SETV1 / 2 is automatically calculated) or
starting point P1x of the 1st axis of the plane (for G17 X)
4)
5 L2/Y1 S_SETV1 Distance L2 between the pole and measuring point P2 in the direction of the 1st axis of the
plane
3)
or starting point P1y of the 2nd axis of the plane (for G17 Y)
4)
6 L3/X2 S_SETV2 Distance L3 between the pole and measuring point P3 in the direction of the 2nd axis of the
plane
3)
(if the distance L3=0, then for a corner that is not right angled, L3 = M_SETV3 / 2 is auto‐
matically calculated)
or starting point P2x of the 1st axis of the plane
4)
7 L4/Y2 S_SETV3 Distance L4 between the pole and measuring point P3 in the direction of the 2nd axis of the
plane with a corner that is not right angled
3)
or starting point P2y of the 2nd axis of the plane
4)
8 XP/X3 S_SETV4 Position of the pole in the 1st axis of the plane
3)
or starting point P3x of the 1st axis of the plane
4)
9 XP/Y3 S_SETV5 Position of the pole in the 2nd axis of the plane
3)
or starting point P3y of the 2nd axis of the plane
4)
10 X4 S_SETV6 Starting point P4x of the 1st axis of the plane
4)
11 Y4 S_SETV7 Starting point P4y of the 2nd axis of the plane
4)
12 X0 S_SETV8 Setpoint of the measured corner in the 1st axis of the plane for correcting in WO
13 Y0 S_SETV9 Setpoint of the measured corner in the 2nd axis of the plane for correcting in WO
14 α0 S_STA1 Starting angle from the positive direction of the 1st axis of the plane to the reference edge of
the workpiece in the MCS (+-270 degrees)
15 α1 S_INCA Angle between workpiece reference edges when measuring a non-right-angled corner
7)
16 DZ S_ID Infeed amount at the measuring height for each measuring point for active protection zone
(see S_MVAR).
Work preparation
3.25 Programming cycles externally
NC programming
1176 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
