Address iden‐
tifier (default
setting)
Address type Modal/
non-
modal
G90/
G91
IC AC DC,
ACN,
ACP
CIC,
CAC,
CDC,
CACN,
CACP
PR,
PM
QU Max.
num‐
ber
Data type of the
assigned value
SD Spline degree m 1 Unsigned
INT
TU Axis angle s 1 Unsigned
INT
STAT Position of joints m 1 Unsigned
INT
SF Starting point off‐
set for thread
cutting
m 1 REAL
DISCL Safety clear‐
ance SAR
s 1 Unsigned
REAL
DISR Repositioning
clearance / SAR
clearance
s 1 Unsigned
REAL
DISPR Path differential
for repositioning
s 1 Unsigned
REAL
ALF Rapid lift angle m 1 Unsigned
INT
DILF Rapid lift length m 1 REAL
FP Fixed point:
Number of fixed
point to be ap‐
proached
s 1 Unsigned
INT
RNDM Modal rounding m 1 Unsigned
REAL
RND Non-modal
rounding
s 1 Unsigned
REAL
CHF Chamfer non-
modal
s 1 Unsigned
REAL
CHR Chamfer in origi‐
nal direction of
motion
s 1 Unsigned
REAL
ANG Contour angle s 1 REAL
ISD Insertion depth m 1 REAL
DISC Transition circle
overshoot tool
radius compen‐
sation
m 1 Unsigned
REAL
OFFN Offset contour
normal
m 1 REAL
DITS Thread run-in
path
m 1 REAL
DITE Thread run-out
path
m 1 REAL
Tables
4.2 Addresses
NC programming
1242 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
