Protection areas
Identifier Parameter Explanation
1. 2. 3. 4. 5.
CPROT INT:
Number of the
protection
area
INT: Option
0: Protection
area OFF
1: Preactivate
protection
area
2: Protection
area ON
3: Preactivate
protection
area with con‐
ditional stop,
only with pro‐
tection areas
active
REAL: Offset
of the protec‐
tion area in
the first geom‐
etry axis
REAL: Offset
of the protec‐
tion area in
the second
geometry axis
REAL: Offset
of the protec‐
tion area in
the third ge‐
ometry axis
Channel-specific pro‐
tection area ON/OFF
NPROT INT:
Number of the
protection
area
INT: Option
0: Protection
area OFF
1: Preactivate
protection
area
2: Protection
area ON
3: Preactivate
protection
area with con‐
ditional stop,
only with pro‐
tection areas
active
REAL: Offset
of the protec‐
tion area in
the first geom‐
etry axis
REAL: Offset
of the protec‐
tion area in
the second
geometry axis
REAL: Offset
of the protec‐
tion area in
the third ge‐
ometry axis
Machine-specific pro‐
tection area ON/OFF
Preprocessing / single block
Identifier Parameter Explanation
STOPRE Preprocessing stop until all prepared blocks in the main
run are executed
SBLOF Suppress single-block processing
SBLON Cancel suppression of the single-block processing
Tables
4.4 Predefined procedures
NC programming
1274 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
