ASCALE X... Y... Z...
The ASCALE command is used to program scale changes to be added to existing frames. In this
case, the last valid scale factor is multiplied by the new one.
The currently set or last programmed coordinate system is used as the reference for the scale
change.
Scaling and offset
Note
If an offset is programmed with ATRANS after SCALE, the offset values will also be scaled.
Fundamentals
2.12 Coordinate transformations (frames)
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 327
