Syntax
TOFRAME/TOFRAMEZ/TOFRAMEY/TOFRAMEX
...
TOROTOF
TOROT/TOROTZ/TOROTY/TOROTX
...
TOROTOF
PAROT
...
PAROTOF
Meaning
TOFRAME: Align Z axis of the WCS by rotating the frame parallel to the tool orientation
TOFRAMEZ: As TOFRAME
TOFRAMEY: Align Y axis of the WCS by rotating the frame parallel to the tool orientation
TOFRAMEX: Align X axis of the WCS by rotating the frame parallel to the tool orientation
TOROT: Align Z axis of the WCS by rotating the frame parallel to the tool orientation
The rotation defined with TOROT is the same as that defined with TOFRAME.
TOROTZ: As TOROT
TOROTY: Align Y axis of the WCS by rotating the frame parallel to the tool orientation
TOROTX: Align X axis of the WCS by rotating the frame parallel to the tool orientation
TOROTOF: Deactivate orientation parallel to tool orientation
PAROT: Rotate frame to align workpiece coordinate system on workpiece
Translations, scaling and mirroring in the active frame remain valid
PAROTOF: The workpiece-specific frame rotation activated with PAROT is deactivated
with PAROTOF.
Note
The TOROT statement ensures consistent programming with active orientable toolholders for
each kinematic type.
Just as in the situation for rotatable toolholders, PAROT can be used to activate a rotation of the
work table. This defines a frame which changes the position of the workpiece coordinate
system in such a way that no compensatory movement is performed on the machine. Language
command PAROT is not rejected if no toolholder with orientation capability is active.
Fundamentals
2.12 Coordinate transformations (frames)
NC programming
334 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
