Meaning
GFRAME<n>
:
Activation of the grinding frame <n> of the data management
G group:
64
Basic position:
MD20150 $MC_GCODE_RESET_VALUES[
63
]
Effectiveness:
Modal
<n>
:
Number of the grinding frame
Range of values:
0, 1, 2, ... 100
Fundamentals
2.12 Coordinate transformations (frames)
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
341
340
342
