Parameter Description Unit
Position
● Front
● Rear
● Inside
● Outside
D Maximum depth infeed - (only for ∇) mm
XDA First grooving limit tool (abs) – (only for face machining direction). mm
XDB Second grooving limit tool (abs) – (only for face machining direction). mm
UX or U Finishing allowance in X or finishing allowance in X and Z – (only for ∇) mm
UZ Finishing allowance in Z – (only for UX) mm
DI For zero: Continuous cut - (only for ∇) mm
BL Blank description (only for ∇)
● Cylinder (described using XD, ZD)
● Allowance (XD and ZD on the finished part contour)
● Contour (additional CYCLE62 call with blank contour – e.g. cast iron mold)
XD - (only for ∇ machining)
- (only for blank description, cylinder and allowance)
● For blank description, cylinder
– Version, absolute:
Cylinder dimension ∅ (abs)
– Version incremental:
Allowance (inc) to maximum values of the CYCLE62 finished part contour
● For blank description, allowance
– Allowance on the CYCLE62 finished part contour (inc)
mm
ZD - (only for ∇ machining)
- (only for blank description, cylinder and allowance)
● For blank description, cylinder
– Version, absolute:
Cylinder dimension (abs)
– Version incremental:
Allowance (inc) to maximum values of the CYCLE62 finished part contour
● For blank description, allowance
– Allowance on the CYCLE62 finished part contour (inc)
mm
Allowance Allowance for pre-finishing - (only for ∇∇∇)
● Yes
U1 contour allowance
● No
mm
U1 Compensation allowance in X and Z direction (inc) – (only for allowance)
● Positive value: Compensation allowance is retained
● Negative value: Compensation allowance is removed in addition to finishing
allowance
mm
Set machining area
limits
Set machining area limits
● Yes
● No
Programming technological functions (cycles)
10.5 Contour turning - Milling/turning machine
Milling
622 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
