Parameter Description Unit
XA
XB
ZA
ZB
With limited machining area only, yes:
1st limit XA ∅
2nd limit XB ∅ (abs) or 2nd limit referred to XA (inc)
1st limit ZA
2nd limit ZB (abs) or 2nd limit referred to ZA (inc)
mm
N Number of grooves
DP Distance between grooves mm
* Unit of feedrate as programmed before the cycle call
Parameters in the "Input simple" mode
G code program parameters ShopMill program parameters
Input
● simple
PRG Name of the program to be generated T Tool name
D Cutting edge number
S / V Spindle speed or
constant cutting rate
rpm
m/min
Parameter Description Unit
TC Name of the swivel data set
Note: The selection box only appears if more than one swivel data set has been set up.
Retraction
(for ShopMill pro‐
gram)
● No
The axis is not retracted before swiveling
● Z
Retraction in the direction of machine axis Z
● Z,X,Y
Move machining axes to retraction position before swiveling
● Tool direction, max.
Maximum retraction (up to the software end position) in the tool direction
● Tool direction, inc.
Incremental retraction (specified retraction distance, up to the software end position)
in the tool direction
When retracting in the tool direction, in the swiveled machine state, several axes can
move (travel).
Programming technological functions (cycles)
10.5 Contour turning - Milling/turning machine
Milling
Operating Manual, 08/2018, 6FC5398-7CP41-0BA0 623
