Siemens MICROMASTER 430 User Manual

Issue 01/05 Attachment
CANopen Option Module Operating Instructions
6SE6400-5BC00-0BP0
123
8 Attachment
8.1 Technical data
Table 8-1 Technical data
Order No. 6SE6400-1CB00-0AA0
Size
(Height x Width x Depth) 161 mm x 73 mm x 43.5 mm
Degree of pollution Degree of pollution 2 according to IEC 60 664-1 (DIN VDE
0110/T1),
moisture condensation during operation is not permissible
Mechanical strength
Stationary
- deflection
- acceleration
During transport
- deflection
- acceleration
Acc. to DIN IEC 60 068-2-6 (with a correctly installed module)
0.15 mm frequency range between 10 Hz and 58 Hz
19.6 m/s
2
frequency range from > 58 Hz to 500 Hz
3.5 mm frequency range between 5 Hz and 9 Hz
9.8 m/s
2
frequency range from > 9 Hz to 500 Hz
Climatic Class (in
operation)
Class 3K3 according to DIN IEC 60 721-3-3
Cooling type Air self-cooling
Permissible ambient or
cooling-medium
temperature
- operation
- storage
- transport
–10 °C to +50 °C (14 °F to 122 °F)
–40 °C to +70 °C (–40 °F to 158 °F)
–25 °C to +70 °C (–13 °F to 158 °F)
Relative air humidity
(perm. humidity class)
In operation
During transport and
storage
<= 85 % rF (moisture condensation not permissible)
<= 95 % rF
Power supply Power is supplied to the CAN bus from the MICROMASTER's
power supply
Output voltage None
Data transfer rate 10, 20, 50, 125, 250, 500, 800 kbaud and 1Mbaud

Siemens MICROMASTER 430 Specifications

General

Power Range	7.5 kW to 250 kW
Voltage Range	380V to 480V
Frequency Range	0 Hz to 650 Hz
Protection Class	IP20
Input Frequency	47 Hz to 63 Hz
Digital Inputs	6
Cooling Method	Forced-air cooling
Communication	USS
Protection Features	Overvoltage, undervoltage, overcurrent, short-circuit, ground fault, overtemperature
Analog Inputs	2
Digital Outputs	3
Analog Outputs	2
Ambient Temperature	-10°C to +50°C
Control Type	Sensorless vector control
