Siemens MICROMASTER 430 User Manual

Issue 01/05 Attachment
CANopen Option Module Operating Instructions
6SE6400-5BC00-0BP0
125
8.3 List of Abbriviations
AC Alternating current
AD Analog digital converter
ADC Analog digital converter
ADR Address
AFM Additional frequency modification
AIN Analog input
AOP Advanced operator panel
AOUT Analog output
ASP Analog setpoint
ASVM Asymmetric space vector modulation
BCC Block check character
BCD Binary-coded decimal code
BI Binector input
BICO Binector / connector
BO Binector output
BOP Basic operator panel
C Commissioning
CAL CAN Application Layer
CAN Controller Area Network
CB Communication board
CCS Client Command Specifier
CCW Counter-clockwise
CDS Command data set
CI Connector input
CiA CAN in Automation
CM Configuration management
CMD Commando
CMM Combimaster
CO Connector output
CO/BO Connector output / Binector output
COB-ID Communication Object Identifier
COM Common (terminal that is connected to NO or NC)
COM-Link Communication link
CT Commissining, ready to run
CT Constant torque
CUT Commissining, run, ready to run

Siemens MICROMASTER 430 Specifications

General

Power Range	7.5 kW to 250 kW
Voltage Range	380V to 480V
Frequency Range	0 Hz to 650 Hz
Protection Class	IP20
Input Frequency	47 Hz to 63 Hz
Digital Inputs	6
Cooling Method	Forced-air cooling
Communication	USS
Protection Features	Overvoltage, undervoltage, overcurrent, short-circuit, ground fault, overtemperature
Analog Inputs	2
Digital Outputs	3
Analog Outputs	2
Ambient Temperature	-10°C to +50°C
Control Type	Sensorless vector control
