PROFIBUS Optional Board Operating instructions
26 6SE6400-5AK00-0BP0
Table 3-3 Request identifier (master -> converter)
0HDQLQJ 5HVSRQVHLGHQWLILHU
5HTXHVW
LGHQWLILHU
SRVLWLYH QHJDWLYH
0 No request 0 7 / 8
1 Request parameter value 1 / 2
↑
2 Modify parameter value (word) 1

3 Modify parameter value (double word) 2

4 Request descriptive element 1 3

6 Request parameter value (array) 1 4 / 5

7 Modify parameter value (array, word) 2 4

8 Modify parameter value (array, double word) 2 5

9 Request number of array elements 6

11 Modify parameter value (array, double word) and store
in EEPROM 2
5

12 Modify parameter value (array, word) and store in
EEPROM 2
4

13 Modify parameter value (double word) and store in
EEPROM
2
↓
14 Modify parameter value (word) and store in EEPROM 1 7 / 8
Table 3-4 Response identifier (converter -> master)
5HVSRQVH
LGHQWLILHU
0HDQLQJ
0 No response
1 Transfer parameter value (word)
2 Transfer parameter value (double word)
3 Transfer descriptive element 1
4 Transfer parameter value (array word) 2
5 Transfer parameter value (array double word) 2
6 Transfer number of array elements
7 Cannot process request (with error number)
8 No master control status for PKW interface
1 The desired element of the parameter description is specified in IND (2
nd
word)
2 The desired element of the indexed parameter is specified in IND (2
nd
word)
