7ML19985CN01 Milltronics SF 500 - INSTRUCTION MANUAL Page 79
mmmmm
Communications
Type Description Start # R
Parameter
Values
Read Reference
Format
Format Word for 32 bit
variables
40,062 1 0 - 1 r/w see page 80
ID Device Identifier 40,064 1 2 r see page 80
Handshaking
Area
(Parameter
Access)
Parameter 40,090 1 0-999 r/w
see page 80
Primary Index 40,091 1 0 - 9 r/w
Secondary Index 40,092 1 0 - 9 r/w
Format Word 40,093 1 bit mapped r/w
Read Value (word 1) 40,094 2 32 bits r
Write Value (word 1) 40,096 2 32 bits r/w
Date and Time
YYYY 41,000 1 1996-2069 r/w
see P008
page 94 and
page 83
MM 41,001 1 1 - 12 r/w
DD 41,002 1 1 - 31 r/w
hh 41,003 1 00 - 23 r/w
see P009
page 94 and
page 83
mm 41,004 1 00 - 59 r/w
ss 41,005 1 00 - 59 r/w
Time Zone 41,006 1 -12 - 12 r/w
see P739
page 114
Process Values
Rate 41,010 2 32 bits r
see page 84Total 1 41,016 2 32 bits r
Total 2 41,018 2 32 bits r
Device State 41,020 1 bit mapped r see page 84
Command Control 41,022 1 bit mapped r/w see page 85
Multi-Span Selection 41,024 1 1 - 8 r/w
see page 38
and P365 on
page 104
Total 1 decimal places 41,025 1 1 - 3 r/w see page 85
Total 2 decimal places 41,026 1 1 - 3 r/w see page 85
PID 1 Setpoint 41,040 2 32 bits r/w
see P416
page 109
PID 2 Setpoint 41,042 2 32 bits r/w
Batch Setpoint 41,044 2 32 bits r/w
see P564
page 109
Batch Prewarn Setpoint 41,046 2 32 bits r/w
see P567
page 110
I/O
Discrete Input 41,070 1 bit mapped r
see page 86
Relay Outputs 41,080 1 bit mapped
mA Inputs 41,090 2 0000 - 20,000 r
mA Outputs 41,110 3 0000 - 20,000 r
Diagnostic Diagnostic State 41,200 1 number code r see page 95
