6-12
History Log
Event Type
Identifies the type of history event that is
being reported. The following event types
are arranged in groups. The modifier fields
for each group are different.
Group 1 types:
ACK. ALARM Alarm block acknowledge
ACK. TRBL. Trouble block acknowledge
ACK. SEC. Security block acknowl-
edge
ACK. SUP. Supervisory block acknowl-
edge
MAN. RST. Manual reset via MKB-4
COLD RST. Hard reset from power off
WARM RST. Hard reset via reset jumper
WDOG RST. Hard reset via 6805
watchdog
VERIFY Alarm verify
ENERGIZE Energize an output
DE-ENERGIZE De-energize an output
ARM Arm a device
DIS-ARM Disarm a device
SILENCE Silence audibles
UNSILENCE Unsilence audibles
CONFIG. (CSG-M) Configuration
changed
Group 2 types:
ALARM Alarm causing device
event
TROUBLE Trouble causing device
event
SECURTY Security causing device
event
SUPERVS Supervisory causing device
event
Group 3 types:
SENS Sensitivity set
Group 4 types:
LOGIN Operator login
Group 5 types:
OUTPUT Output logic event
Modifier
The modifier is an optional field that
extends the meaning of the event type. For
example, ALARM IN, where IN explains the
ALARM type.
Group 1 type:
No modifiers for this group
Group 2 types:
IN Condition now active
OUT Condition now inactive
ACK Condition now acknowledged
Group 3 types:
Hi_3
Hi_2
Hi_1
NORMAL
Low_1
Low_2
Low_3
Group 4 types:
0 Lowest access
1
2
3 Highest access
Group 5 types:
ON Condition now active
OFF Condition now inactive
Event Locator
This field locates the source or destination
