2-6
Installation
Figure 28
UPS Wiring Diagram
NOTES:
1. All wires 14 AWG min,
600V insulation.
2. Wiring to the printer and
PIM-2 must be 14 AWG
min, 600V insulation in
conduit.
3. Use the UPS ICS Lifeline
Model 9300057.
4. Standby Power
requirements: 120 VAC,
0.6A for 24 hours.
5. Standby Power
requirements: 120 VAC,
0.15A for 24 hours.
PIM-2/PAL-1
The PIM-2 and printer require a standby
power source in the event of a loss of
primary input power (AC mains). Refer to
Figure 28 for the connection of a UPS to
meet this requirement.
1. Before installing a PIM-2 in the MXL-IQ
system, a PIM-1 must be already
installed.
2. Wiring from the PIM-1 to the PIM-2 must
be within 25 feet in rigid conduit (Refer to
Table 3).
3ELBAT
STNEMERIUQERECAFRETNI2-MIPOT1-MIP
)rellatsniybdeilppuS(
.oNniPtpnI2-MIPOTBT,1-MIP
)xR(4
)xT(5
7
)YSUB(3
)NOMMOC(2
)DxT(2
)DxR(3
)STC,STR(5,4
)RTD(02
)DRG(7
.muminimeriw
GWA81esU
3. Figure 29 shows the proper installation
of the PIM-2 with the MXL-IQ system.
4. Programming the CSG-M is required
when using a PIM-2 and parallel printer.
Configure one of the following four
printer types on the MKB-4:
Supervised PIM-2 80 column color
Supervised PIM-2 132 column color
Supervised PIM-2 80 column
Supervised PIM-2 132 column (for
PAL-1 and NFPA 72 Proprietary)
5. Set the dipswitches on the back of the
PIM-2 to agree with the communications
parameters configured in the CSG-M.
Refer to Table 4 for the dipswitch
definitions.
8. Install the MOM-2 or MOM-4
If a system requires the MOM-2 or MOM-4
optional card cage (Figures 10 and 11,
page 20), now is the time to install it.
Unpack the card cage and its attached
backplate and inspect it, looking for such
things as connectors not properly
installed, dirt, and packing material on the
board.
The MOM-2/4 installation kits include the
following items
2-MOM4-MOM
stun01#3stun01#4
srehsawtalf01#3srehsawtalf01#4
srehsawkcol01#3srehsawkcol01#4
swercs61/7x6#4elbacnobbirrotc
udnoc-81
swercs61/5x23-6#2selbaceriw-22
elbacnobbirrotcudnoc-81sediugdrac4
selbaceriw-22
sediugdrac2
To Next Page
