2-9
Installation
3. If a connection to a MOD-16 module on
another rail is required, use the optional
cable P/N 555-190941.
MID-16 (See Figure 19, page 1-11)
1. Mount the MID-16 in one System 3 type
module space using the four screws
provided.
2. Connect the MID-16 to the module to its
left with the 10-position ribbon cable P/N
555-190940 provided. This module may
be either an MOI-7, MOD-16, or MID-16.
3. If a connection to a module on another
rail is required, use the optional cable
P/N 555-190941.
4. Connect the other end of the 2-wire
cable into P5 on the MOM-2/4. The
2-wire cable that attaches P5 on the
MOM-2/4 with P3 on the SMB-2 feeds
24 VDC full-wave unfiltered DC power to
the MOM-2/4. This is the main power
used by the optional modules. The
8-conductor ribbon cable supplies 5 VDC
and communication between the SMB-2
and the MOM-2/4.
9. Install the MOI-7, MOD-16, and
MID-16
MOI-7
1. Mount the MOI-7.
The MOI-7 mounts on a System 3 rail in
two module spaces. Mount the MOI-7
using the four screws provided.
2. Set the network address on S1.
Set the address according to Table 16 at
the end of this chapter so that it agrees
with the address assigned in CSG-M.
3. Use P6 to set the mode for common
alarm relay K1. (See Figure 17,
page 1-10, for the location of P6.)
K1 is a common alarm relay that can be
programmed to transfer back to normal
when the MXL-IQ is silenced.
Use jumper P6 on the MOI-7 to select the
desired mode according to the table below.
noitisoP6PedoM
AelbaecneliSyaleRmralA
Belbaecnelis-noNyaleRmralA
MOD-16 (See Figure 18, page 1-10)
1. Mount the MOD-16 in one System 3 type
module space using the four screws
provided.
2. Connect the MOD-16 to the MOI-7 with
the 10-position ribbon cable P/N 555-
190940 provided with the MOI-7.
5ELBAT
STNERRUCDAOLELUDOMMUMIXAM
I2-DLA
003-IMC
4-MRC
4-MSC
4-MZC
R1-MIN
)mralanisecived021(Am09
Am69
)dezigren
esyaler4(Am57
)detcennocsecnailppagnitacidnimralaon(Am43
)mralanisenoz4htiwmumixam(Am027
Am0
5BT2-BMSmorf
nwardsirewopontahtsemussaelpmaxegniwollofehT
.)2#CAN,1#CANdnarewop6B1-MZC(
:elpmaxE
+27.0=tnerrucdaollatoteht,4-MSC1+4-MRC1+4-MZC1htiW
A38.0=430.0+570.0
=38.0-)6-SPM(0.6ro)21-SPM(0.21=tnerrucelbaliavagniniamerehT
.)6-SPM(38.5ro)21-SPM(38.11
.rewopCANrofdesuebyamtnerrucgniniamerehT
