Description
38/293 Revision 11 • INSTALLATION AND OPERATING INSTRUCTIONS • NXPLUS C • 802-9081.9
Installation possibilities for cable connections and surge arresters, single-core PE- and XLPE-insulated
Circuit-breaker panel 1250 A
1
● Disconnector panel 1250 A
1
Panel spacing 600 mm
Make Conductor
cross-
section
2
Insulation
Cable T-plugs Coupling inserts/
coupling plugs
Surge arresters with coupling inserts According to
standard
[mm
2
] bolted bolted Arresters Coupling inserts
• GOST
(Russia, CIS)
• GB/DL (China)
12 kV
24 kV*
12 kV
24 kV*
additionally
1 cable per panel and phase
Nexans
Euromold
35…300 EPDM 1x 430TB/G - 300SA-5(10)SA - IEC, GOST, GB/DL
1x K430TB/G* - 300SA-5(10)SA - IEC
1x K430TB/G-CSxxx* - 300SA-5(10)SA - GOST, GB/DL
35…300 EPDM 1x 480TB/G - 800SA-10-xxx - IEC, GOST, GB/DL
1x K480TB/G* - 800SA-10-xxx - IEC
50…630 EPDM 1x 484TB/G - 800SA-10-xxx - IEC
35…630 1x K484TB/G* - 800SA-10-xxx - IEC
800…1200 EPDM 1x 489TB/G - 800SA-10-xxx - IEC
1x K489TB/G* - 800SA-10-xxx - IEC
Südkabel 50…300 Silicon
e
1x SET 12 - MUT 23 - IEC, GOST, GB/DL
25…240 1x SET 24* - MUT 23 - IEC, GOST, GB/DL
300…500 Silicon
e
1x SEHDT 13 - MUT 23 - IEC, GOST, GB/DL
300…630 1x SEHDT 23* - MUT 23 - IEC, GOST, GB/DL
nkt cables 25…300 Silicon
e
1x CB 12-630 - CSA 12-x - IEC
25…500 1x CB 17,5-630 - CSA 17,5-x - GOST, GB/DL
25…300 1x CB 24-630* - CSA 24-x - IEC, GOST, GB/DL
185…500 Silicon
e
1x CB 24-1250-2 - CSA 12-x - IEC
95…500 1x CB 24-1250-2* - CSA 24-x - IEC
400…630 Silicon
e
1x CB 36-630(1250) - CSA 12-x - IEC, GOST, GB/DL
1x CB 36-630(1250)* - CSA 24-x - IEC, GOST, GB/DL
630…1000 Silicon
e
1x CB 42-1250-3 - CSA 12-x - IEC
1x CB 42-1250-3* - CSA 24-x - IEC
Tyco
Electronics
Raychem
25…300 Silicon
e
1x RSTI-58xx - RSTI-CC-58SAxxxx - IEC
1x RSTI-58xx* - RSTI-CC-68SAxxxx RSTI-SA-PIN IEC
25…300 Silicon
e
1x RSTI-58xx-CEE01 - RSTI-CC-58SAxxxx - GOST
1x RSTI-58xx-CEE01* - RSTI-CC-68SAxxxx RSTI-SA-PIN GOST
400…800 Silicon
e
1x RSTI-395x - RSTI-CC-58SAxxxx RSTI-SA-PIN IEC
1x RSTI-595x* - RSTI-CC-68SAxxxx RSTI-SA-PIN IEC
400…800 Silicon
e
1x RSTI-595x-CEE01 - RSTI-CC-58SAxxxx RSTI-SA-PIN GOST
1x RSTI-595x-CEE01* - RSTI-CC-68SAxxxx RSTI-SA-PIN GOST
3M 50…240 Silicon
e
1x 93-EE 705-6 - - - IEC, GOST, GB/DL
25…240 1x 93-EE 705-6* - - - IEC, GOST, GB/DL
300…400 Silicon
e
1x 93-EE 715-6 - - - IEC, GOST, GB/DL
1x 93-EE 715-6* - - - IEC, GOST, GB/DL
GCA 35…500 Silicon
e
1x CJB10-630 - - - GB
25…500 1x CJB20-630* - - - GB
ABB
Kabeldon
25…630 EPDM 1x CSE-A 12630-xx - - - IEC, GOST
1x CSE-A 24630-xx* - - - IEC, GOST
Cellpack 50…400 EPDM 1x CTS 630A 24kV - CTKSA - IEC
25…300 1x CTS 630A 24kV* - CTKSA - IEC
Ample 25…400 EPDM 1x AQT3-15/630 - AHY5WZ7 - GB/DL
35…500 1x AQT3-24/630* - AHY5WZ7 - GB/DL
