Description
40/293 Revision 11 • INSTALLATION AND OPERATING INSTRUCTIONS • NXPLUS C • 802-9081.9
Cellpack 50…400 EPDM 2x CTS 630A 24kV 1x CKS 630A 24kV CTKSA - IEC
25…300 2x CTS 630A 24kV* 1x CKS 630A 24kV* CTKSA - IEC
50…240 EPDM 1x CTS 630A 24kV 1x CTKS 630A 24kV CTKSA - IEC
25…240 1x CTS 630A 24kV* 1x CTKS 630A 24kV* CTKSA - IEC
Ample 25…400 EPDM 1x AQT3-15/630 1x AHT3-15/630 AHY5WZ7 - GB/DL
35…500 1x AQT3-24/630* 1x AHT3-24/630* AHY5WZ7 - GB/DL
3 cables per panel and phase
Nexans
Euromold
35…300 EPDM 1x 430TB/G 2x 300PB/G 300SA-5(10)SA - IEC, GOST, GB/DL
1x K430TB/G* 2x K300PB/G* 300SA-5(10)SA - IEC
1x K430TB/G-CSxxx* 2x K300PB/G-CSxxx* 300SA-5(10)SA - GOST, GB/DL
35…300 EPDM 3x 480TB/G 2x 800PB/G 800SA-10-xxx - IEC, GOST, GB/DL
3x K480TB/G* 2x K800PB/G* 800SA-10-xxx - IEC
50…630 EPDM 1x 484TB/G 2x 804PB/G 800SA-10-xxx - IEC
35…630 1x K484TB/G* 2x K804PB/G* 800SA-10-xxx - IEC
800…1200 EPDM 1x 489TB/G 2x 809PB/G 800SA-10-xxx - IEC
1x K489TB/G* 2x K809PB/G* 800SA-10-xxx - IEC
nkt cables 25…300 Silicon
e
1x CB 12-630 2x CC 12-630 CSA 12-x - IEC
25…500 1x CB 17,5-630 2x CC 17,5-630 CSA 17,5-x - GOST, GB/DL
25…300 1x CB 24-630* 2x CC 24-630* CSA 24-x - IEC, GOST, GB/DL
25…300 Silicon
e
3x CB 12-630 2x CP 630-C - - IEC
3x CB 24-630* 2x CP 630-C* - - IEC, GOST, GB/DL
185…500 Silicon
e
1x CB 24-1250-2 2x CC 24-1250-2 CSA 12-x - IEC
95…500 1x CB 24-1250-2* 2x CC 24-1250-2* CSA 24-x - IEC
185…500 Silicon
e
3x CB 24-1250-2 2x CP 630-C - - IEC
95…500 3x CB 24-1250-2* 2x CP 630-C* - - IEC
400…630 Silicon
e
1x CB 36-630(1250) 2x CC 36-630(1250) CSA 12-x - IEC, GOST, GB/DL
1x CB 36-630(1250)* 2x CC 36-630(1250)* CSA 24-x - IEC, GOST, GB/DL
400…630 Silicon
e
3x CB 36-630(1250) 2x CP 630-M16 - - IEC, GOST, GB/DL
3x CB 36-630(1250)* 2x CP 630-M16* - - IEC, GOST, GB/DL
630…1000 Silicon
e
1x CB 42-1250-3 2x CC 42-2500-3 CSA 12-x - IEC
1x CB 42-1250-3* 2x CC 42-2500-3* CSA 24-x - IEC
Tyco
Electronics
Raychem
25…300 Silicon
e
1x RSTI-58xx 2x RSTI-CC-58xx RSTI-CC-58SAxxxx - IEC
1x RSTI-58xx* 2x RSTI-CC-58xx* RSTI-CC-68SAxxxx RSTI-SA-PIN IEC
25…300 Silicon
e
1x RSTI-58xx-CEE01 2x RSTI-CC-58xx-CEE01 RSTI-CC-58SAxxxx - GOST
1x RSTI-58xx-CEE01* 2x RSTI-CC-58xx-CEE01* RSTI-CC-68SAxxxx RSTI-SA-PIN GOST
400…800 Silicon
e
1x RSTI-395x 2x RSTI-CC-395x RSTI-CC-58SAxxxx RSTI-SA-PIN IEC
1x RSTI-595x* 2x RSTI-CC-595x* RSTI-CC-68SAxxxx RSTI-SA-PIN IEC
400…800 Silicon
e
1x RSTI-595x-CEE01 2x RSTI-CC-595x-CEE01 RSTI-CC-58SAxxxx RSTI-SA-PIN GOST
1x RSTI-595x-CEE01* 2x RSTI-CC-595x-CEE01* RSTI-CC-68SAxxxx RSTI-SA-PIN GOST
Cellpack 50…240 EPDM 1x CTS 630A 24kV 2x CTKS 630A 24kV - - IEC
25…240 1x CTS 630A 24kV* 2x CTKS 630A 24kV* - - IEC
4 cables per panel and phase
Nexans
Euromold
35…300 EPDM 1x 430TB/G 3x 300PB/G - - IEC, GOST, GB/DL
1x K430TB/G* 3x K300PB/G* - - IEC
1x K430TB/G-CSxxx* 3x K300PB/G-CSxxx* - - GOST, GB/DL
35…300 EPDM 1x 480TB/G 3x 800PB/G - - IEC
1x K480TB/G* 3x K800PB/G* - - IEC
50…630 EPDM 1x 484TB/G 3x 804PB/G - - IEC
35…630 1x K484TB/G* 3x K804PB/G* - - IEC
800…1200 EPDM 1x 489TB/G 3x 809PB/G - - IEC
1x K489TB/G* 3x K809PB/G* - - IEC
Circuit-breaker panel 1250 A
1
● Disconnector panel 1250 A
1
Panel spacing 600 mm
Make Conductor
cross-
section
2
Insulation
Cable T-plugs Coupling inserts/
coupling plugs
Surge arresters with coupling inserts According to
standard
[mm
2
] bolted bolted Arresters Coupling inserts
• GOST
(Russia, CIS)
• GB/DL (China)
12 kV
24 kV*
12 kV
24 kV*
additionally
