Südkabel 50…300 Silicone 2x SET 12 2x SEHDK 13.1 MUT 23 - IEC, GOST, GB/DL
25…240 2x SET 24* 2x SEHDK 23.1* MUT 23 - IEC, GOST, GB/DL
50…300 Silicone 4x SET 12 2x KU 23.2 MUT 23 - IEC, GOST, GB/DL
25…240 4x SET 24* 2x KU 23.2* MUT 23 - IEC, GOST, GB/DL
300…500 Silicone 4x SEHDT 13 2x KU 23 MUT 23 - IEC, GOST, GB/DL
300…630 4x SEHDT 23* 2x KU 23* MUT 23 - IEC, GOST, GB/DL
nkt cables 25…300 Silicone 2x CB 12-630 2x CC 12-630 CSA 12-x - IEC
25…500 2x CB 17.5-630 2x CC 12-630 CSA 17.5-x - GOST, GB/DL
25…300 2x CB 24-630* 2x CC 24-630* CSA 24-x - IEC, GOST, GB/DL
25…300 Silicone 4x CB 12-630 2x CP 630-C CSA 12-x - IEC
4x CB 24-630* 2x CP 630-C* CSA 24-x - IEC, GOST, GB/DL
185…500 Silicone 2x CB 24-1250-2 2x CC 24-1250-2 CSA 12-x - IEC
95…500 2x CB 24-1250-2* 2x CC 24-1250-2* CSA 24-x - IEC
185…500 Silicone 4x CB 24-1250-2 2x CP 630-C CSA 12-x - IEC
95…500 4x CB 24-1250-2* 2x CP 630-C* CSA 24-x - IEC
400…630 Silicone 2x CB 36-630(1250) 2x CC 36-630(1250) CSA 12-x - IEC, GOST, GB/DL
2x CB 36-630(1250)* 2x CC 36-630(1250)* CSA 24-x - IEC, GOST, GB/DL
400…630 Silicone 4x CB 36-630(1250) 2x CP 630-M16 CSA 12-x - IEC, GOST, GB/DL
4x CB 36-630(1250)* 2x CP 630-M16* CSA 24-x - IEC, GOST, GB/DL
Tyco
Electronics
Raychem
25…300 Silicone 2x RSTI-58xx 2x RSTI-CC-58xx RSTI-CC-58SAxxxx - IEC
2x RSTI-58xx* 2x RSTI-CC-58xx* RSTI-CC-68SAxxxx RSTI-SA-PIN IEC
25…300 Silicone 2x RSTI-58xx-CEE01 2x RSTI-CC-58xx-CEE01 RSTI-CC-58SAxxxx - GOST
2x RSTI-58xx-CEE01* 2x RSTI-CC-58xx-CEE01* RSTI-CC-68SAxxxx RSTI-SA-PIN GOST
400…800 Silicone 2x RSTI-395x 2x RSTI-CC-395x RSTI-CC-58SAxxxx RSTI-SA-PIN IEC
2x RSTI-595x* 2x RSTI-CC-595x* RSTI-CC-68SAxxxx RSTI-SA-PIN IEC
400…800 Silicone 2x RSTI-595x-CEE01 2x RSTI-CC-595x-CEE01 RSTI-CC-58SAxxxx RSTI-SA-PIN GOST
2x RSTI-595x-CEE01* 2x RSTI-CC-595x-CEE01* RSTI-CC-68SAxxxx RSTI-SA-PIN GOST
3M 50…240 Silicone 4x 93-EE 705-6 2x KU 23.2 - - IEC, GOST, GB/DL
25…240 4x 93-EE 705-6* 2x KU 23.2* - - IEC, GOST, GB/DL
240 Silicone 2x 93-EE 705-6 2x 93-EE 718-6 - - IEC, GOST, GB/DL
150…240 2x 93-EE 705-6* 2x 93-EE 718-6* - - IEC, GOST, GB/DL
300…400 Silicone 4x 93-EE 715-6 2x KU 23.2 - - IEC, GOST, GB/DL
4x 93-EE 715-6* 2x KU 23.2* - - IEC, GOST, GB/DL
GCA 35…500 Silicone 2x CJB10-630 2x CJBK10-630 - - GB
25…500 2x CJB20-630* 2x CJBK20-630* - - GB
ABB
Kabeldon
25…630 EPDM 4x CSE-A 12630-xx 2x PC 630-3 - - IEC, GOST
4x CSE-A 24630-xx* 2x PC 630-3* - - IEC, GOST
Cellpack 50…400 EPDM 4x CTS 630A 24kV 2x CKS 630A 24kV - - IEC
25…300 4x CTS 630A 24kV* 2x CKS 630A 24kV* - - IEC
50…240 EPDM 2x CTS 630A 24kV 2x CTKS 630A 24kV CTKSA - IEC
25…240 2x CTS 630A 24kV* 2x CTKS 630A 24kV* CTKSA - IEC
Ample 25…400 EPDM 2x AQT3-15/630 2x AHT3-15/630 AHY5WZ7 - GB/DL
35…500 2x AQT3-24/630* 2x AHT3-24/630* AHY5WZ7 - GB/DL
6 cables per panel and phase
Nexans
Euromold
35…300 EPDM 2x 430TB/G 4x 300PB/G 300SA-5(10)SA - IEC, GOST, GB/DL
2x K430TB/G* 4x K300PB/G* 300SA-5(10)SA - IEC
2x K430TB/G-CSxxx* 4x K300PB/G-CSxxx* 300SA-5(10)SA - GOST, GB/DL
35…300 EPDM 6x 480TB/G 4x 800PB/G 800SA-10-xxx - IEC, GOST, GB/DL
6x K480TB/G* 4x K800PB/G* 800SA-10-xxx - IEC
50…630 EPDM 2x 484TB/G 4x 804PB/G 800SA-10-xxx - IEC
35…630 2x K484TB/G* 4x K804PB/G* 800SA-10-xxx - IEC
Circuit-breaker panel and disconnector panel 2000 A, 2500 A (panel spacing 900 mm)
Make Conductor
cross-
section
1
Insulation
Cable T-plugs Coupling inserts/
coupling plugs
Surge arresters with According to
standard
[mm
2
] bolted bolted Arresters Coupling inserts
• GOST
(Russia, CIS)
• GB/DL (China)
12 kV
24 kV*
12 kV
24 kV*
additionally
