Description
44/293 Revision 11 • INSTALLATION AND OPERATING INSTRUCTIONS • NXPLUS C • 802-9081.9
nkt cables 25…300 Silicone 2x CB 12-630 4x CC 12-630 CSA 12-x - IEC
25…500 2x CB 17.5-630 4x CC 12-630 CSA 17.5-x - GOST, GB/DL
25…300 2x CB 24-630* 4x CC 24-630* CSA 24-x - IEC, GOST, GB/DL
25…300 Silicone 6x CB 12-630 4x CP 630-C - - IEC
6x CB 24-630* 4x CP 630-C* - - IEC, GOST, GB/DL
185…500 Silicone 2x CB 24-1250-2 4x CC 24-1250-2 CSA 12-x - IEC
95…500 2x CB 24-1250-2* 4x CC 24-1250-2* CSA 24-x - IEC
185…500 Silicone 6x CB 24-1250-2 4x CP 630-C - - IEC
95…500 6x CB 24-1250-2* 4x CP 630-C* - - IEC
400…630 Silicone 2x CB 36-630(1250) 4x CC 36-630(1250) CSA 12-x - IEC, GOST, GB/DL
2x CB 36-630(1250)* 4x CC 36-630(1250)* CSA 24-x - IEC, GOST, GB/DL
Tyco
Electronics
Raychem
25…300 Silicone 2x RSTI-58xx 4x RSTI-CC-58xx RSTI-CC-58SAxxxx - IEC
2x RSTI-58xx* 4x RSTI-CC-58xx* RSTI-CC-68SAxxxx RSTI-SA-PIN IEC
25…300 Silicone 2x RSTI-58xx-CEE01 4x RSTI-CC-58xx-CEE01 RSTI-CC-58SAxxxx - GOST
2x RSTI-58xx-CEE01* 4x RSTI-CC-58xx-CEE01* RSTI-CC-68SAxxxx RSTI-SA-PIN GOST
400…800 Silicone 2x RSTI-395x 4x RSTI-CC-395x RSTI-CC-58SAxxxx RSTI-SA-PIN IEC
2x RSTI-595x* 4x RSTI-CC-595x* RSTI-CC-68SAxxxx RSTI-SA-PIN IEC
400…800 Silicone 2x RSTI-595x-CEE01 4x RSTI-CC-595x-CEE01 RSTI-CC-58SAxxxx RSTI-SA-PIN GOST
2x RSTI-595x-CEE01* 4x RSTI-CC-595x-CEE01* RSTI-CC-68SAxxxx RSTI-SA-PIN GOST
Cellpack 50…240 EPDM 2x CTS 630A 24kV 4x CTKS 630A 24kV - - IEC
25…240 2x CTS 630A 24kV* 4x CTKS 630A 24kV* - - IEC
8 cables per panel and phase
Nexans
Euromold
35…300 EPDM 2x 430TB/G 6x 300PB/G - - IEC, GOST, GB/DL
2x K430TB/G* 6x K300PB/G* - - IEC
2x K430TB/G-CSxxx* 6x K300PB/G-CSxxx* - - GOST, GB/DL
35…300 EPDM 2x 480TB/G 6x 800PB/G - - IEC
2x K480TB/G* 6x K800PB/G* - - IEC
50…630 EPDM 2x 484TB/G 6x 804PB/G - - IEC
35…630 2x K484TB/G* 6x K804PB/G* - - IEC
nkt cables 185…500 Silicone 2x CB 24-1250-2 6x CC 24-1250-2 - - IEC
95…500 2x CB 24-1250-2* 6x CC 24-1250-2* - - IEC
Tyco
Electronics
Raychem
25…300 Silicone 2x RSTI-58xx 6x RSTI-CC-58xx - - IEC
2x RSTI-58xx 6x RSTI-CC-58xx - - IEC
25…300 Silicone 2x RSTI-58xx-CEE1 6x RSTI-CC-58xx-CEE1 - - GOST
2x RSTI-58xx-CEE1 6x RSTI-CC-58xx-CEE1 - - GOST
1
Observe the actual current- and short-circuit-carrying capacity of the cables and sealing ends.
Circuit-breaker panel and disconnector panel 2000 A, 2500 A (panel spacing 900 mm)
Make Conductor
cross-
section
1
Insulation
Cable T-plugs Coupling inserts/
coupling plugs
Surge arresters with According to
standard
[mm
2
] bolted bolted Arresters Coupling inserts
• GOST
(Russia, CIS)
• GB/DL (China)
12 kV
24 kV*
12 kV
24 kV*
additionally
