Description
Installation possibilities for cable connections and surge arresters, three-core PE- and XLPE-insulated
Circuit-breaker panel 630 A, 1000 A ● Switch-disconnector panel 630 A ● Disconnector panel 1000 A ● Ring-main panel 630 A ● Vacuum
contactor panel ● Circuit-breaker panel with top-rear cable connection 1250 A
1
Panel spacing 600 mm
Make Conductor
cross-
section
2
Insulation
Cable T-plugs Coupling inserts/
coupling plugs
Distribution kit for
three-core cables
Surge arresters According to
standard
[mm
2
] bolted bolted additionally
• GOST (Russia,
CIS)
• GB/DL (China)
12 kV
24 kV*
12 kV
24 kV*
1 cable per panel and phase
Nexans
Euromold
35…300 EPDM 1x 430TB/G - 1x distribution kit 300SA-5(10)SA IEC, GOST, GB/DL
1x K430TB/G* - 1x distribution kit* 300SA-5(10)SA IEC
1x K430TB/G-CSxxx* - 1x distribution kit* 300SA-5(10)SA GOST, GB/DL
35…300 EPDM 1x 480TB/G - 1x distribution kit 800SA-10-xxx IEC, GOST, GB/DL
1x K480TB/G* - 1x distribution kit* 800SA-10-xxx IEC
Südkabel 50…300 Silicon
e
1x SET 12 - 1x distribution kit SAT MUT 23 IEC, GOST, GB/DL
25…240 1x SET 24* - 1x distribution kit SAT* MUT 23 IEC, GOST, GB/DL
nkt cables 25…300 Silicon
e
1x CB 12-630 - 1x distribution kit ATS CSA 12-x IEC
25…500 1x CB 17,5-630 - 1x distribution kit ATS CSA 17,5-x GOST, GB/DL
25…300 1x CB 24-630* - 1x distribution kit ATS* CSA 24-x IEC, GOST, GB/DL
185…500 Silicon
e
1x CB 24-1250-2 - 1x distribution kit ATS CSA 12-x IEC
95…500 1x CB 24-1250-2* - 1x distribution kit ATS* CSA 24-x IEC
Tyco
Electronics
Raychem
25…300 Silicon
e
1x RSTI-58xx - 1x distribution kit RSTI-
TRF0x
RSTI-CC-58SAxxxx IEC
1x RSTI-58xx* - 1x distribution kit RSTI-
TRF0x*
RSTI-CC-68SAxxxx IEC
25…300 Silicon
e
1x RSTI-58xx-CEE01 - 1x distribution kit RSTI-
TRF0x
RSTI-CC-58SAxxxx GOST
1x RSTI-58xx-CEE01* - 1x distribution kit RSTI-
TRF0x*
RSTI-CC-68SAxxxx GOST
3M 50…240 Silicon
e
1x 93-EE 705-6 - 1x distribution kit - IEC, GOST, GB/DL
25…240 1x 93-EE 705-6* - 1x distribution kit* - IEC, GOST, GB/DL
300…400 Silicon
e
1x 93-EE 715-6 - 1x distribution kit - IEC, GOST, GB/DL
1x 93-EE 715-6* - 1x distribution kit* - IEC, GOST, GB/DL
GCA 35…500 Silicon
e
1x CJB10-630 - 1x distribution kit - GB
25…500 1x CJB20-630* - 1x distribution kit* - GB
ABB
Kabeldon
25…300 EPDM 1x CSE-A 12630-xx - 1x distribution kit - IEC, GOST
1x CSE-A 24630-xx* - 1x distribution kit* - IEC, GOST
Cellpack 50…400 EPDM 1x CTS 630A 24kV - 1x distribution kit CTKSA IEC
25…300 1x CTS 630A 24kV* - 1x distribution kit* CTKSA IEC
Ample 25…400 EPDM 1x AQT3-15/630 - 1x distribution kit AHY5WZ7 GB/DL
35…500 1x AQT3-24/630* - 1x distribution kit* AHY5WZ7 GB/DL
2 cables per panel and phase
Nexans
Euromold
35…300 EPDM 1x 430TB/G 1x 300PB/G 2x distribution kit 300SA-5(10)SA IEC, GOST, GB/DL
1x K430TB/G* 1x K300PB/G* 2x distribution kit* 300SA-5(10)SA IEC
1x K430TB/G-CSxxx* 1x K300PB/G-CSxxx* 2x distribution kit* 300SA-5(10)SA GOST, GB/DL
35…300 EPDM 2x 480TB/G 1x 800PB/G 2x distribution kit 800SA-10-xxx IEC, GOST, GB/DL
2x K480TB/G* 1x K800PB/G* 2x distribution kit* 800SA-10-xxx IEC
Südkabel 50…300 Silicon
e
1x SET 12 1x SEHDK 13.1 2x distribution kit SAT - IEC, GOST, GB/DL
25…240 1x SET 24* 1x SEHDK 23.1* 2x distribution kit SAT* - IEC, GOST, GB/DL
50…300 Silicon
e
2x SET 12 1x KU 23.2 2x distribution kit SAT - IEC, GOST, GB/DL
25…240 2x SET 24* 1x KU 23.2* 2x distribution kit SAT* - IEC, GOST, GB/DL
