Description
46/293 Revision 11 • INSTALLATION AND OPERATING INSTRUCTIONS • NXPLUS C • 802-9081.9
nkt cables 25…300 Silicon
e
1x CB 12-630 1x CC 12-630 2x distribution kit ATS CSA 12-x IEC
25…500 1x CB 17,5-630 1x CC 17,5-630 2x distribution kit ATS CSA 17,5-x GOST, GB/DL
25…300 1x CB 24-630* 1x CC 24-630* 2x distribution kit ATS* CSA 24-x IEC, GOST, GB/DL
25…300 Silicon
e
2x CB 12-630 1x CP 630-C 2x distribution kit ATS CSA 12-x IEC
2x CB 24-630* 1x CP 630-C* 2x distribution kit ATS* CSA 24-x IEC, GOST, GB/DL
185…500 Silicon
e
1x CB 24-1250-2 1x CC 24-1250-2 2x distribution kit ATS CSA 12-x IEC
95…500 1x CB 24-1250-2* 1x CC 24-1250-2* 2x distribution kit ATS* CSA 24-x IEC
185…500 Silicon
e
2x CB 24-1250-2 1x CP 630-C 2x distribution kit ATS CSA 12-x IEC
95…500 2x CB 24-1250-2* 1x CP 630-C* 2x distribution kit ATS* CSA 24-x IEC
Tyco
Electronics
Raychem
25…300 Silicon
e
1x RSTI-58xx 1x RSTI-CC-58xx 2x distribution kit RSTI-
TRF0x
RSTI-CC-58SAxxxx IEC
1x RSTI-58xx* 1x RSTI-CC-58xx* 2x distribution kit RSTI-
TRF0x*
RSTI-CC-68SAxxxx IEC
25…300 Silicon
e
1x RSTI-58xx-CEE01 1x RSTI-CC-58xx-CEE01 2x distribution kit RSTI-
TRF0x
RSTI-CC-58SAxxxx GOST
1x RSTI-58xx-CEE01* 1x RSTI-CC-58xx-
CEE01*
2x distribution kit RSTI-
TRF0x*
RSTI-CC-68SAxxxx GOST
3M 50…240 Silicon
e
2x 93-EE 705-6 1x KU 23.2 2x distribution kit - IEC, GOST, GB/DL
25…240 2x 93-EE 705-6* 1x KU 23.2* 2x distribution kit* - IEC, GOST, GB/DL
240 Silicon
e
1x 93-EE 705-6 1x 93-EE 718-6 2x distribution kit - IEC, GOST, GB/DL
150…240 1x 93-EE 705-6* 1x 93-EE 718-6* 2x distribution kit* - IEC, GOST, GB/DL
300…400 Silicon
e
2x 93-EE 715-6 1x KU 23.2 2x distribution kit - IEC, GOST, GB/DL
2x 93-EE 715-6* 1x KU 23.2* 2x distribution kit* - IEC, GOST, GB/DL
GCA 35…500 Silicon
e
1x CJB10-630 1x CJBK10-630 2x distribution kit - GB
25…500 1x CJB20-630* 1x CJBK20-630* 2x distribution kit* - GB
ABB
Kabeldon
25…300 EPDM 2x CSE-A 12630-xx 1x PC 630-3 2x distribution kit - IEC, GOST
2x CSE-A 24630-xx* 1x PC 630-3* 2x distribution kit* - IEC, GOST
Cellpack 50…400 EPDM 2x CTS 630A 24kV 1x CKS 630A 24kV 2x distribution kit - IEC
25…300 2x CTS 630A 24kV* 1x CKS 630A 24kV* 2x distribution kit* - IEC
50…240 EPDM 1x CTS 630A 24kV 1x CTKS 630A 24kV 2x distribution kit CTKSA IEC
25…240 1x CTS 630A 24kV* 1x CTKS 630A 24kV* 2x distribution kit* CTKSA IEC
Ample 25…400 EPDM 1x AQT3-15/630 1x AHT3-15/630 2x distribution kit AHY5WZ7 GB/DL
35…500 1x AQT3-24/630* 1x AHT3-24/630* 2x distribution kit* AHY5WZ7 GB/DL
3 cables per panel and phase
Nexans
Euromold
35…300 EPDM 1x 430TB/G 2x 300PB/G 3x distribution kit - IEC, GOST, GB/DL
1x K430TB/G* 2x K300PB/G* 3x distribution kit* - IEC
1x K430TB/G-CSxxx* 2x K300PB/G-CSxxx* 3x distribution kit* - GOST, GB/DL
35…300 EPDM 1x 480TB/G 2x 800PB/G 3x distribution kit 800SA-10-xxx IEC, GOST, GB/DL
1x K480TB/G* 2x K800PB/G* 3x distribution kit* 800SA-10-xxx IEC
nkt cables 25…300 Silicon
e
1x CB 12-630 2x CC 12-630 3x distribution kit ATS - IEC
25…500 1x CB 17,5-630 2x CC 17,5-630 3x distribution kit ATS - GOST, GB/DL
25…300 1x CB 24-630* 2x CC 24-630* 3x distribution kit ATS* - IEC, GOST, GB/DL
185…500 Silicon
e
1x CB 24-1250-2 2x CC 24-1250-2 3x distribution kit ATS - IEC
95…500 1x CB 24-1250-2* 2x CC 24-1250-2* 3x distribution kit ATS* - IEC
Tyco
Electronics
Raychem
25…300 Silicon
e
1x RSTI-58xx 2x RSTI-CC-58xx 3x distribution kit RSTI-
TRF0x
- IEC
1x RSTI-58xx* 2x RSTI-CC-58xx* 3x distribution kit RSTI-
TRF0x*
- IEC
25…300 Silicon
e
1x RSTI-58xx-CEE01 2x RSTI-CC-58xx-CEE01 3x distribution kit RSTI-
TRF0x
- GOST
1x RSTI-58xx-CEE01* 2x RSTI-CC-58xx-
CEE01*
3x distribution kit RSTI-
TRF0x*
- GOST
Circuit-breaker panel 630 A, 1000 A ● Switch-disconnector panel 630 A ● Disconnector panel 1000 A ● Ring-main panel 630 A ● Vacuum
contactor panel ● Circuit-breaker panel with top-rear cable connection 1250 A
1
Panel spacing 600 mm
Make Conductor
cross-
section
2
Insulation
Cable T-plugs Coupling inserts/
coupling plugs
Distribution kit for
three-core cables
Surge arresters According to
standard
[mm
2
] bolted bolted additionally
• GOST (Russia,
CIS)
• GB/DL (China)
12 kV
24 kV*
12 kV
24 kV*
