Siemens NXPLUS C

Description
50/293 Revision 11 • INSTALLATION AND OPERATING INSTRUCTIONS • NXPLUS C • 802-9081.9
Thermoplastic-insulated cables 15/17.5/24 kV (according to IEC 60502-2 and VDE 0276-620)
Paper-insulated belted cables (non-draining cables) ≤ 12 kV (according to IEC 60055 and VDE 0255)
Cable type Cable sealing end Remark
Make Type Cross-section
[mm
2
]
1-core cable, PE- and
XLPE-insulated
N2YSY (Cu) and N2XSY
(Cu)
or
NA2YSY (Al) and NA2XSY
(Al)
Nexans Euromold K430TB/G 35...300 EPDM with conductive layer
K480TB/G 35...300 EPDM with conductive layer
K484TB/G 35...630 EPDM with conductive layer
K489TB/G 800...1200 EPDM with conductive layer
nkt cables CB 24-630 25...300 Silicone with conductive layer (optionally with metal housing)
CB 24-1250-2 95...500 Silicone with conductive layer
CB 36-630(1250) 400...630 Silicone with conductive layer
CB 42-1250-3 630...1000 Silicone with conductive layer
Südkabel SET 24 50...300 Silicone with conductive layer (optionally with metal housing)
SEHDT 23 400...500 Silicone with conductive layer (optionally with metal housing)
Tyco Electronics
Raychem
RSTI-58xx 25...300 Silicone with conductive layer, with capacitive measuring
point
RSTI-595x 400...800 Silicone with conductive layer, with capacitive measuring
point
3M 93-EE 705-6 25...240 Silicone with conductive layer (optionally with metal housing)
93-EE 715-6 300...400 Silicone with conductive layer (optionally with metal housing)
GCA CJB20-630 35...500 Silicone with conductive layer
ABB Kabeldon CSE-A 24630-xx 25...630 EPDM with conductive layer
Cellpack CTS 630A 24kV 25...300 EPDM with conductive layer, with capacitive measuring point
Ample AQT3-24/630 35...500 EPDM with conductive layer
3-core cable, PE and XLPE-
insulated
N2YSY (Cu) and N2XSY
(Cu)
or
NA2YSY (Al) and NA2XSY
(Al)
Nexans Euromold K430TB/G 35...300 EPDM with conductive layer, in combination with distribution
kit
K480TB/G 35...300 EPDM with conductive layer, in combination with distribution
kit
nkt cables CB 24-630 25...300 Silicone with conductive layer (optionally with metal housing),
in combination with distribution kit
CB 24-1250-2 185...500 Silicone with conductive layer, in combination with
distribution kit
Südkabel SET 24 50...300 Silicone with conductive layer (optionally with metal housing),
in combination with distribution kit
SEHDT 23 400...500 Silicone with conductive layer (optionally with metal housing),
in combination with distribution kit
Tyco Electronics
Raychem
RSTI-58xx 25...300 Silicone with conductive layer, with capacitive measuring
point, in combination with distribution kit RSTI-TRF0x
3M 93-EE 705-6 25...240 Silicone with conductive layer (optionally with metal housing),
in combination with distribution kit
93-EE 715-6 300...400 Silicone with conductive layer (optionally with metal housing),
in combination with distribution kit
GCA CJB20-630 35...500 Silicone with conductive layer, in combination with
distribution kit
ABB Kabeldon CSE-A 24630-xx 25...630 EPDM with conductive layer, in combination with distribution
kit
Cellpack CTS 630A 24kV 25...300 EPDM with conductive layer, with capacitive measuring point,
in combination with distribution kit
Ample AQT3-24/630 35...500 EPDM with conductive layer, in combination with distribution
kit
Cable type Cable sealing end Remark
Make Type Cross-section [mm
2
]
3-core cable, paper-insulated
NKBA (Cu), NKBY (Cu), NKRA
(Cu) and NKFA (Cu)
or
NAKBA (Al), NAKBY (Al),
NAKRA (Al) and NAKFA (Al)
Nexans Euromold 430TB/G 35...300 EPDM with conductive layer, in combination
with distribution kit MIND
nkt cables CB 24-630 25...240 Silicone with conductive layer (optionally
with metal housing), in combination with
transition sealing end type SÜEV 10
