802-9081.9 • INSTALLATION AND OPERATING INSTRUCTIONS • NXPLUS C • Revision 11 51/293
Description
Paper-insulated belted cables (non-draining cables) ≤ 12 kV (according to GOST 18410-73)
Paper-insulated belted cables (mass-impregnated cables) ≤ 12 kV (according to IEC 60055 and VDE 0255)
Paper-insulated belted cables (mass-impregnated cables) ≤ 12 kV (according to GOST 18410-73)
Commercially available bar systems
Surge-proof caps
Cable type Cable sealing end Remark
Make Type Cross-section [mm
2
]
3-core cable, paper-insulated
ASB and ASBL
Nexans Euromold 430TB/G 35...300 EPDM with conductive layer, in combination
with distribution kit MIND
nkt cables CB 24-630 25...240 Silicone with conductive layer (optionally
with metal housing), in combination with
transition sealing end type SÜEV 10
Cable type Cable sealing end Remark
Make Type Cross-section [mm
2
]
3-core cable, paper-insulated
NKBA (Cu), NKBY (Cu), NKRA
(Cu) and NKFA (Cu)
or
NAKBA (Al), NAKBY (Al),
NAKRA (Al) and NAKFA (Al)
nkt cables CB 24-630 25...240 Silicone with conductive layer (optionally
with metal housing), in combination with
transition sealing end type SÜEV 10
Cable type Cable sealing end Remark
Make Type Cross-section [mm
2
]
3-core cable, paper-insulated
ASB and ASBL
nkt cables CB 24-630 25...240 Silicone with conductive layer (optionally
with metal housing), in combination with
transition sealing end type SÜEV 10
Bar type Bar connection Remark
Make Type Conductor material Maximum rated current
Solid-insulated
busbars
MGC Moser Glaser Duresca DE Copper 1250 A / 2500 A Outer sheath made of polyamide
(polyamide tube)
Duresca DG Copper 1250 A / 2500 A Outer sheath made of CrNi steel or
aluminum (metal sheath)
Preissinger ISOBUS MB Copper 1250 A / 2500 A Outer sheath made of epoxy resin
(with heat shrinkable tube, if
required)
Ritz SIS Copper 1250 A / 2500 A Outer sheath made of epoxy resin
(with heat shrinkable tube, if
required)
Make Type Size Rated voltage Remark
3M SP 33 Outside cone type "C" 12 kV Silicone with semi-conductive layer
SP 33 Outside cone type "C" 24 kV
Nexans Euromold 400DR-B Outside cone type "C" 12 kV EPDM with semi-conductive layer
K400DR-B Outside cone type "C" 24 kV
nkt cables CBC 40,5-630 Outside cone type "C" 12 kV Silicone with semi-conductive layer
CBC 40,5-630 Outside cone type "C" 24 kV
Südkabel SP 33 Outside cone type "C" 12 kV Silicone with semi-conductive layer
SP 33 Outside cone type "C" 24 kV
Cellpack CIK Outside cone type "C" 12 kV EPDM with semi-conductive layer
CIK Outside cone type "C" 24 kV
Ample AJM-15/630 Outside cone type "C" 12 kV EPDM with semi-conductive layer
AJM-24/630 Outside cone type "C" 24 kV
