Siemens NXPLUS C User Manual

Installation
90/293 Revision 11 • INSTALLATION AND OPERATING INSTRUCTIONS • NXPLUS C • 802-9081.9
GCA CJBxx-630 448 CJBKxx-630 333 - - - - - -
ABB Kabeldon CSE-A xx630-xx 448 CSE-A xx630-xx 276 - - - - - -
CSE-A xx630-03 448 CSE-A xx630-03 268 - - - - - -
Cellpack CTS 630A 24kV 448 CTS 630A 24kV 241 - - - - - -
CTS 630A 24kV 448 CTKS 630A 24kV 333 CTKS 630A 24kV 218
Ample AQT3-15/630 448 AHT3-15/360 348 - - - - - -
Solid-insulated bar Moser-Glaser 437 - - - - - - - - - - - -
Preissinger - - -
Ritz - - -
Make 1st cable 2nd cable 3rd cable
Plug type Distance [mm] Plug type Distance [mm] Plug type Distance [mm]

Siemens NXPLUS C Specifications

General

Rated voltage	Up to 24 kV
Rated frequency	50/60 Hz
Protection degree	IP4X
Insulation medium	SF6
Standards	IEC 62271-200
Operating mechanism	Spring-operated
