Table 2-1 SICAM FCM and Accessories Ordering Information
Description Order Number
SICAM FCM
•
Voltage measurements: LoPo VTs according to IEC 60044-7, IEC 61869-11,
conventional VT and 230 V
•
Current measurements: LoPo CTs according to IEC 60044-8, IEC 61869-10
•
Fault indicator with directional information and measurements of V, I, f, P,
Q, S, cos φ, and power-flow direction
•
Panel mounted
•
Dimensions in mm: 96 × 48 × 109.5
•
1 digital input
•
2 digital outputs
•
Modbus RTU
6MD2321-1AA00-1AA0/XX
1
SICAM FCM
•
For voltage measurement with LRM voltage-detecting systems according
to IEC 61243-5
•
Current measurements: LoPo CTs according to IEC 60044-8, IEC 61869-10
•
Fault indicator with directional information and measurements of V, I, f, P,
Q, S, cos φ, and power-flow direction
•
Panel mounted unit with display
•
Dimensions in mm: 96 × 48 × 109.5
•
1 digital input
•
2 digital outputs
•
Modbus RTU
•
The mandatory interface cable (6MD2322-0AA80-0AB3) for linkage to the
Voltage-Detection System (VDS) has to be ordered separately.
6MD2322-1AA00-1AA0/XX
1
Voltage-Detection System (VDS) Interface Cable
•
4-wire connection lead with integrated protection circuit to connect
SICAM FCM 6MD2322-1AA00-1AA0/CC with the LRM voltage detection
system
•
1 ground input
•
Length: 0.3 m
•
Mandatory accessory for each SICAM FCM 6MD2322-1AA00-1AA0 with
hardware revision number “CC” or higher
6MD2322-0AA80-0AB3
Adapter 1 A to low power IEC 60044-8
•
3 inputs, transformer ratio 225 mV@1 A
•
Accuracy class: 1
•
Thermal overload: 100 A for 1 s
•
Coil diameter: 5.8 mm
6MD2320-0AA10-1AA0
Adapter 5 A to low power IEC 60044-8
•
3 inputs, transformer ratio 225 mV@5 A
•
Accuracy class: 3
•
Thermal overload: 100 A for 1 s
•
Coil diameter: 5.8 mm
6MD2320-0AA20-1AA0
1
XX represents the hardware revision number
Introduction
2.1 Overview
16 SICAM, Feeder Condition Monitor, Manual
E50417-H8940-C580-A4, Edition 03.2019
